Digital Projection TITAN sx+ 3D Dual 3D Ultra Contrast User Manual page 143

Digital Projection
TITAN sx+ 3D, Dual 3D, Ultra Contrast
Optical
throw ratio
full DMD image width
throw distance
lens shift vertical *
pixels (vs DMD height)
lens shift horizontal *
pixels (vs DMD width)
Aperture
Max object field size
Effective focal length
Distortion
Transmission
Mechanical
Lens extension**
(±2%)
Length
Maximum diameter
Weight
* Actual available lens shift is reduced when the lens is to be shifted
in two directions combined (see Shifting the image, in section
2. Installation).
** Lens extension is the distance from the outer end of the lens to the
front of the projector. It is important for calculating throw distance
accurately (see Useful lens calculations, in section 2. Installation).
Rev A August 2009
105-611 ~ 107-197 105-612 ~ 107-198
2.02 - 2.77 : 1 zoom 2.77 - 4.51 : 1 zoom 4.51 - 7.53 : 1 zoom 7.5 - 11.2 : 1 zoom
2.02 : 1 2.77 : 1
1.98 - 11.88m 3.29 - 16.25m
(6.5 - 39ft) (10.8 - 53.3ft)
2.77 : 1 4.51 : 1
1.44 - 8.66m 2.02 - 9.98m
(4.7 - 28.4ft) (6.6 - 32.7ft)
2.02 : 1 2.77 : 1
4 - 24m 9.1 - 45m
(13.1 - 78.7ft) (29.9 - 147.6ft)
2.77 : 1 4.51 : 1
4 - 24m 9.1 - 45m
(13.1 - 78.7ft)) (29.9 - 147.6ft)
+ 525, - 420 + 525, - 420
(+ 0.5, 0.4H) (+ 0.5, 0.4H)
± 280 ± 280
(± 0.2W) (± 0.2W)
F/2.5 F/2.5
34.6mm 34.6mm
(1.36") (1.36")
39.0 - 53.43mm 52.4 - 85.3mm
(1.54 - 2.1") (2.06 - 3.36")
<0.5% <0.5%
> 88 % > 88 %
159 mm 145 mm
(6.3 in) (5.7 in)
311 mm 304 mm
(12.2 in) (12.0 in)
139 mm 139 mm
(5.5 in) (5.5 in)
5.15 kg 5.25 kg
(11.3 lb) (11.6 lb)
User Manual
105-613 ~ 107-199
4.51 : 1
2.66 - 17.74m
(8.7 - 58.2ft)
7.53 : 1
1.59 - 10.62m
(5.2 - 34.8ft)
4.51 : 1
12 - 80m
(39.4 - 262.5ft)
7.53 : 1
12 - 80m
(39.4 - 262.5ft)
+ 525, - 420
(+ 0.5, 0.4H)
± 280
(± 0.2W)
F/2.5
34.6mm
(1.36")
84.86 - 142.03mm
(3.34 - 5.59")
<0.5%
> 88 %
129 mm
(5.1 in)
271 mm
(10.7 in)
139 mm
(5.5 in)
4.70 kg
(10.3 lb)
7. Appendix
109-235 ~ 109-358
7.5 : 1
1.6 - 10.67m
(5.2 - 35ft)
11.2 : 1
1.07 - 7.14m
(3.5 - 23.4ft)
7.5 : 1
12 - 80m
(39.4 - 262.5ft)
11.2 : 1
12 - 80m
(39.4 - 262.5ft)
+ 525, - 420
(+ 0.5, 0.4H)
± 280
(± 0.2W)
F/2.5
34.6 mm
(1.36")
141.2 - 211.4mm
(5.56 - 8.32 in)
<0.5%
>88%
179 mm
(7.0 in)
340 mm
(13.4 in)
139 mm
(5.5 in)
to be confirmed
lens extension, measured from
front of corner post
Page 7.7
