The control panel

Keypad layout

The controls on the keypad are identical to those at the top of the remote control,
and are described on the following pages.

Projector status indicators

The indicators on the control panel are as follows:
Power off = NO POWER
green = normal RUNNING mode
Shutter amber = CLOSED
Error off = NO ERROR
flashing = ERROR (temperature)
IR blue flash = Remote control command received
Lamp 1 off = OFF
flashing red = LAMP ERROR
flashing green = LAMP WARM-UP
Lamp 2 off = OFF
flashing red = LAMP ERROR
flashing green = LAMP WARM-UP
Rev A August 2009 Rev A August 2009
amber = STANDBY mode
green = OPEN
steady = ERROR (voltage)
green = ON (100%) amber = (80 - 99%)
flashing amber = COOL-DOWN
green = ON (100%) amber = (80 - 99%)
flashing amber = COOL-DOWN
User Manual User Manual
Many features are controlled
from the menus using the menu
navigation keys on the remote
control or keypad.
For more information about
using the menus, see later in
this section, Using the menus.
Some of the menu features, for
example brightness, contrast
and input preset operations, can
be accessed directly using the
control keys at the bottom of
the remote control.
Other features, eg zoom and
focus, are controlled using the
control keys at the top of the
remote control and keypad.
For more information about
using the control keys, see
later in this section, Using the
control keys.
The Lamp 2 indicators apply
only to Dual models.
