For important information about how to control the projector when Input 8 is being used, see the final pages of Section 4.
4. Controlling the projector 4. Controlling the projector
Setup menu continued

On Screen Display

• Press and to select On Screen Display.
Press to open the On Screen Display submenu.

OSD position

• Press and to select OSD Position
Press and to select from:
Upper Left
Upper Centre
Upper Right
Middle Left
Middle Centre
Middle Right
Lower Left
Lower Centre
Lower Right

OSD Size

• Press and to select OSD Size.
Press and to select from:
Large
Small

OSD Timeout

• Press and to select the length of the On Screen Display Timeout.
Press and to select from:
0 to 255 in 1 second steps (when set to zero, the OSD never times out)
Page 4.42 Page 4.42
Digital Projection Digital Projection
TITAN sx+ 3D, Dual 3D, Ultra Contrast TITAN sx+ 3D, Dual 3D, Ultra Contrast
User Manual User Manual
Notes
Setup Menu

On Screen Display

The On Screen Display will
move to the centre of the DMD
when Blanking is turned On.
(see Geometry menu, earlier in
this section).
If a menu is opened, and no
other key is pressed within the
period set in the OSD Timeout
menu, then the menus will
disappear. When the
is pressed again, the menus will
reopen at the same point they
were last viewed.
Rev A August 2009 Rev A August 2009
key
