For important information about how to control the projector when Input 8 is being used, see the final pages of Section 4.
4. Controlling the projector
4. Controlling the projector

Red, Green and Blue

Press
,
or
or ON.

Test pattern

Press
to select a test pattern.

Picture settings

Press a
key, followed by
Brightness
Contrast
Saturation
Phase
Aspect ratio

Geometry settings

Keystone adjustment is used to correct for distortion caused by the projector being
mounted higher or lower than the screen.
Press Keystone
followed by
and
Press Position
followed by
,
,
smaller than the DMD:
Page 4.14
Page 4.14
Digital Projection
Digital Projection
to switch the red, green or blue components OFF
and
to adjust these picture settings:
BRI
CON
SAT
PHASE
ASPECT
KEYST,
to adjust the keystone correction:
POS,
and
to adjust the picture position, for images
TITAN sx+ 3D, Dual 3D, Ultra Contrast
TITAN sx+ 3D, Dual 3D, Ultra Contrast
User Manual
User Manual
Notes
The red, green and blue keys
are disabled when the OSD is
switched OFF.
For more information about test
patterns, see Setup menu, later
in this section.
The Saturation control is
available for Composite, S-
Video and Component inputs
only.
The Phase control is available
for RGB inputs only.
For all adjustments on this page
that require more than one key
to be pressed:
- after 10 seconds, if no
adjustment has been made, the
key must be pressed again
to resume adjustment.
- to end the adjustment before
10 seconds has elapsed, press
a different adjustment key, or
press the
key.
When the OSD is OFF:
- the
keys will still function,
but the controls will not be
visible on screen.
Rev A August 2009
Rev A August 2009
