Digital Projection
TITAN sx+ 3D, Dual 3D, Ultra Contrast
Operation Command examples
All operation commands are located at bytes 9 &10.
All values are located at bytes 17 & 18 unless otherwise indicated
power (0102)
projector On or Standby
Value
00h
On
04h
Standby
Examples
Set Projector (On)
BEEF 03 1900 5858 01 0102 0000 00000000 00000000 00000000 00000000 00000000
Response
1E BEEF 03 1900 5858 01 0102 0000 00000000 00000000 00000000 00000000 00000000
Set Projector (Standby)
BEEF 03 1900 5858 01 0102 0000 00000000 04000000 00000000 00000000 00000000
Response
1E BEEF 03 1900 5858 01 0102 0000 00000000 04000000 00000000 00000000 00000000
Get Projector Power
BEEF 03 1900 5858 02 0102 0000 00000000 00000000 00000000 00000000 00000000
Response (Projector in Standby)
1E BEEF 03 1900 5858 02 0102 0000 00000000 04000000 00000000 00000000 00000000
Rev A August 2009
User Manual
7. Appendix
Notes
Spaces in example messages
are for visual clarity and should
not be sent as part of the
message.
In the example messages
the CRC is set to 5858h. This
value will be ignored. However,
the CRC should ideally be
calculated, as described in the
Titan Projector Series External
Control Protocol.
Page 7.19
