For important information about how to control the projector when Input 8 is being used, see the final pages of Section 4.
4. Controlling the projector 4. Controlling the projector

Colour menu

To return to the main menu, press
From the main menu:
• Press and until Colour is highlighted.
Press to open the Colour menu. The blue highlight moves to the first item in
the menu.
Notes on Colour and Global Colourimetry
Global Colourimetry menu (see later in this section, in Setup menu)
After a calibration check on the projector or venue, a set of Global colour settings
can be made in the Global Colourimetry menu. These settings are then available
to be copied at any time using the Colour Mode setting in the Colour menu, or
used as a starting point using the Trim feature in the Colour menu.
Colour menu (see this section).
The settings made in the Colour menu will be automatically saved in the Mode
History, or can be manually saved to one of the Input Presets (see Input modes
and settings earlier in this section).
The selections available in Colour Mode in the Colour menu are:
Global Copies the settings made in the Global Colourimetry menu
Temperature Set the colour temperature using the slider
User Set the Red, Green and Blue Lift and Gain using the sliders
Peak Preset high brightness setting
Video, Film,
Graphic Applies the factory set P7 settings
ColorMAX User Applies the User gamma settings made externally using the
DP Userware on a personal computer
Page 4.30 Page 4.30
Digital Projection Digital Projection
TITAN sx+ 3D, Dual 3D, Ultra Contrast TITAN sx+ 3D, Dual 3D, Ultra Contrast
up to three times.
User Manual User Manual
Notes
When using the menus, press
OSD or
reveal the On-Screen-Display.

Colour Menu

Some menu items may be
greyed out - unavailable due to
the effect of settings made in
other menus, or due to the type
of input signal.
Read these notes on Colour
and Global Colourimetry
before making any settings in
the Colour menus.
Note that any changes made
in the Global Colourimetry
menu (see Setup Menu, later
in this section) will affect ALL
inputs, modes and presets for
which Global Mode has been
selected in the Colour menu.
Rev A August 2009 Rev A August 2009
to hide or
