Connecting the projector
Rear Input
connection panel
Signal Inputs
The following inputs are available:
4. SDI
1. RGB1
7. Component
8. DVI
Rev A August 2009
Control
Front Input
connection panel
connection panel
5. Composite Video
User Manual
3. DVI
2. RGB2
6. S-Video
MAIN
SUB
3D Sync
2. Installation
Notes
For more information on
selecting an input source, see
section 4. Overview, Using
the control keys, and Using
the menus.
For more information about pin
connections and control codes
see section 7. Appendix.
For more information on
input modes see section
4. Overview.
