2. Installation
Screen requirements
Aspect ratio
Fitting the image to the DMD
If the source image supplied to the projector is smaller than 1400 x 1050 pixels,
then the image will not fill the DMD. The following example shows how a number
of common formats may be displayed.
Images displayed full width
Images displayed full height
4:3 = 1.33:1 (native) = 1400 pixels
Page 2.2
Digital Projection
full width = 1400 pixels
TITAN sx+ 3D, Dual 3D, Ultra Contrast
User Manual
Notes
The images are shown here
scaled automatically by the
projector.
The image may be scaled
differently if the Aspect Ratio is
set differently in the Picture or
Geometry menus.
Rev A August 2009
