For important information about how to control the projector when Input 8 is being used, see the final pages of Section 4.
Digital Projection Digital Projection
TITAN sx+ 3D, Dual 3D, Ultra Contrast TITAN sx+ 3D, Dual 3D, Ultra Contrast
TCGD page continued

Update Graph

• Click on Update Graph to show the effects of the new color gamut graphically.

Save File

Click on Save to save the values on screen to a TCGD file on the computer.
•
When prompted, enter a filename or browse to an existing file that is to be
overwritten.
Open File
• To retrieve a set of saved TCGD values, click on Open .
When prompted, enter a filename or browse to the file that is to be opened.

Download User 1, User 2

• Click on Download User 1 or Download User 2 to save the values on screen to
one of the two ColorMAX User settings on the projector.

Read User 1, User 2

Click on Read User 1 or Read User 2 to replace the values on screen with one
•
of the two ColorMAX User settings on the projector.
Rev A August 2009 Rev A August 2009
User Manual User Manual
Read the notes on MCGD,
TCGD and ColorMAX earlier
in this section before making
any MCGD settings.
TCGD files are named filename.
tcgd.
5. Userware 5. Userware
Notes
Page 5.17 Page 5.17
