For important information about how to control the projector when Input 8 is being used, see the final pages of Section 4.
Digital Projection Digital Projection
TITAN sx+ 3D, Dual 3D, Ultra Contrast TITAN sx+ 3D, Dual 3D, Ultra Contrast

Picture menu

To return to the main menu, press
From the main menu:
• Press and until Picture is highlighted.
Press to open the Picture menu. The blue highlight moves to the first item in
the menu.

Brightness

• Press and to select Brightness.
Press and to adjust the slider (-128 to +127).

Contrast

• Press and to select Contrast.
Press and to adjust the slider (-128 to +127).

Saturation

Adjusts the saturation at white peak levels.
• Press and to select Saturation.
Press and to adjust the slider (0 to 255).

Hue

Adjusts the color balance from green to blue, using the red level as a reference.
• Press and to select Hue.
Press and to adjust the slider (0 to 255).
Rev A August 2009 Rev A August 2009
User Manual User Manual
up to three times.
4. Controlling the projector 4. Controlling the projector
Notes
Some menu controls can be
accessed directly using the
control keys (see earlier in this
section).
When using the menus, press
OSD or
reveal the On-Screen-Display.
Picture Menu
Some menu items may be
greyed out - unavailable due to
the effect of settings made in
other menus, or due to the type
of input signal.
The Saturation slider is
available for Composite, S-
Video and Component inputs
only.
The Hue slider is available for
NTSC inputs only.
to hide or
Page 4.23 Page 4.23
