For important information about how to control the projector when Input 8 is being used, see the final pages of Section 4.
4. Controlling the projector 4. Controlling the projector

Indicators

Input status indicators

4. SDI
The indicator next to each input connector on the rear input panel will light as
follows:
off = input not selected
green = input selected, signal detected and in range
flashing green = input selected, but signal not detected or out of range
3D Sync IN
The indicator next to each input connector on the front input panel will light as
follows:
off = input not selected
flashing green = input selected
Page 4.8 Page 4.8
Digital Projection Digital Projection
1. RGB1
7. Component 5. Composite Video
8. DVI:
MAIN
SUB
3D Sync OUT
TITAN sx+ 3D, Dual 3D, Ultra Contrast TITAN sx+ 3D, Dual 3D, Ultra Contrast
3. DVI
2. RGB2
6. S-Video
User Manual User Manual
Notes
There are more indicators on
the Control panel, and these are
described on the next page.
