For important information about how to control the projector when Input 8 is being used, see the final pages of Section 4.
4. Controlling the projector 4. Controlling the projector
Geometry menu continued

Resolution

• Press and to select Resolution.
Press to open the Resolution submenu.

Input Detection

• Press and to select from:
Automatic
Allows the projector to automatically detect an appropriate
input mode for the signal.
Manual Allows the user to select an appropriate input mode from a list
of common standards.
Custom Allows the user to completely customise the settings to suit the
incoming video signal.
When Input Detection is set to Manual:
• Press and to select Input Standard.
• Press and to select from:
720p
XGA
XGA+
SXGA-
SXGA
SXGA+
1080p
UXGA
VGA
NTSC
PAL
SVGA
Page 4.28 Page 4.28
Digital Projection Digital Projection
TITAN sx+ 3D, Dual 3D, Ultra Contrast TITAN sx+ 3D, Dual 3D, Ultra Contrast
User Manual User Manual
Notes
Geometry Menu

Resolution

Input Detection should
normally be set to Automatic.
However, if the incoming video
signal is non-standard, the
projector may not be able to
select an appropriate input
mode.
In this case, Input Detection
should be set to Manual or
Custom.
Input Standard is available
only if Input Detection is set to
Manual.
