Digital Projection
TITAN sx+ 3D, Dual 3D, Ultra Contrast
Brightness
sx+ 3D
sx+ 3D Ultra Contrast
sx+ Dual 3D
sx+ Dual 3D Ultra Contrast
Colour temperature

Electrical

Inputs
Pixel clock
Control inputs
Indicators
Mains supply
Single
Dual
International Regulations

Physical

Operating Temperature
Storage Temperature
Thermal Dissipation
Single
Dual
Operating Humidity
Weight
FCC WIFI ID
R68WIPORT
Rev A August 2009
4500 ANSI lumens ±10%
2500 ANSI lumens ±10%
9000 ANSI lumens ±10% in dual lamp mode
4500 ANSI lumens ±10% in dual lamp mode
Native: 7500°K (±1000°K), White balance adjustment: 3000°K - 10000°K
RGB1, RGB2, DVI-Single, SDI, Composite Video, S-Video, Component
DVI-Single/Dual/Twin/3D
up to 165MHz
1 x 3D
1 x LAN
1 x wifi LAN
1 x RS232 serial: 19200 baud, 8 bits, 1 stop bit, no parity
1 x remote control
Input, Power, Shutter, Error, IR, Lamp 1, Lamp 2
580W, 100-240VAC ±10%, 48-62Hz (single phase)
910W, 100-240VAC ±10%, 48-62Hz (single phase)
Meets FCC Class A requirements
Meets EMC Directives (EN 55022, EN 55024, EN 55103)
Meets Low Voltage Directive (EN60950)
0 to 40°C
-10 to 50°C
1770 BTU/hr
2777 BTU/hr
20% to 80% non-condensing
approximately 31 kg (68 lbs)
User Manual 7. Appendix
Page 7.5
