Aspect Ratio; Sharpness - Digital Projection TITAN sx+ 3D Dual 3D Ultra Contrast User Manual

For important information about how to control the projector when Input 8 is being used, see the final pages of Section 4.
Digital Projection Digital Projection
TITAN sx+ 3D, Dual 3D, Ultra Contrast TITAN sx+ 3D, Dual 3D, Ultra Contrast
picture menu continued

Aspect Ratio

• Press and to select Aspect Ratio.
Press and to select from:
Fill This will best fit the incoming source to fill either the height or
width without changing the aspect ratio of the source.
User Aspect
1.33:1 (4:3)
1.6:1 (16:10)
1.78:1 (16:9)
2.35:1 (Scope)
1.66:1 (Vista)
1.85 (Flat)
Native The image will be displayed pixel for pixel. The image will be
centred, with a black border if smaller than 1400 x 1050 or
cropped if larger.

Sharpness

• Press and to select Sharpness.
Press and to adjust the slider.
Rev A August 2009 Rev A August 2009
User Manual User Manual
Aspect Ratio selection can be
found in both the Picture and
Geometry menus.
When User Aspect is selected,
the Aspect Ratio settings are
taken from the User H Aspect
and V Aspect settings made in
the Geometry menu.
The Sharpness slider is
available for Composite,
S-Video and Component SD
inputs only.
4. Controlling the projector 4. Controlling the projector
Notes
Page 4.25 Page 4.25
