Digital Projection
TITAN sx+ 3D, Dual 3D, Ultra Contrast
Shutter (CF02)
Closes and opens shutter
Shutter Close
Shutter Open
Examples
Set Shutter (Close)
BEEF 03 1900 5858 01 CF02 0000 00000000 00000000 00000000 00000000 00000000
Response
1E BEEF 03 1900 5858 01 CF02 0000 00000000 00000000 00000000 00000000 00000000
Set Shutter (Open)
BEEF 03 1900 5858 01 CF02 0000 01000000 00000000 00000000 00000000 00000000
Response
1E BEEF 03 1900 5858 01 CF02 0000 01000000 00000000 00000000 00000000 00000000
Caution: The Set and Get parameters are different:
Get Shutter
BEEF 03 1900 5858 02 CF02 0000 00000000 00000000 00000000 00000000 00000000
Response (Closed)
1E BEEF 03 1900 5858 02 CF02 0000 00000000 01000000 00000000 00000000 00000000
Response (Open)
1E BEEF 03 1900 5858 02 CF02 0000 00000000 00000000 00000000 00000000 00000000
Rev A August 2009
Target
Value
(Set)
(Get)
00h
01h
01h
00h
User Manual
7. Appendix
Notes
Spaces in example messages
are for visual clarity and should
not be sent as part of the
message.
In the example messages
the CRC is set to 5858h. This
value will be ignored. However,
the CRC should ideally be
calculated, as described in the
Titan Projector Series External
Control Protocol.
Page 7.23
