7. Appendix

4. SDI input

1 x 75 ohm BNC
SMPTE 292 / HD-SDI signals are very high speed digital signals which require
better quality coaxial cable than conventional analogue video. The data rate is 1.5
Gigabits per second.
In choosing cable length and connectors for any installation the frequency response
loss in decibels should be proportional to 1Öf, from 1MHz, to 1.5GHz. The following
or similar cable specification should be used to ensure fault free communication
between source and projector:
Belden 8281 cable or equivalent

5. Composite video input

1 x 75 ohm BNC
PAL or NTSC video

6. S-Video input

4 pin mini-DIN
1 Y Ground
2 C Ground
3 Luminance (Y)
4 Chrominance (C)

7. Component video input

4 x 75 ohm BNC
Used for standard definition interlaced signals only
RGsB RGBS
R R
G + Sync G
B B
Sync
Page 7.12
Digital Projection
pin view of female connector
YPrPb
Pr/Cr
Y + Sync
Pb/Cb
TITAN sx+ 3D, Dual 3D, Ultra Contrast
User Manual
Notes
To select the sync format for
RGB signals, see Setup Menu,
in 4.Controlling the Projector.
To select between RGB and
YPrPb signals, see Colour
Menu, in 4.Controlling the
Projector.
