Digital Projection TITAN sx+-500 User Manual

High brightness digital video projector
Hide thumbs Also See for TITAN sx+-500:
Table of Contents

Advertisement

Quick Links

Download this manual
TITAN sx+-500
High Brightness Digital Video Projector
User Manual
105-947C
Rev C
March 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TITAN sx+-500 and is the answer not in the manual?

Questions and answers

Related Manuals for Digital Projection TITAN sx+-500

Summary of Contents for Digital Projection TITAN sx+-500

  • Page 1 TITAN sx+-500 High Brightness Digital Video Projector User Manual 105-947C Rev C March 2008...

  • Page 2: Declaration Of Conformity

    73/23/EEC Low Voltage Equipment Directive, amended by 93/68/EEC. Products covered by this Declaration Large screen video projector type TITAN sx+-500 Basis on which Conformity is being declared The products identified above comply with the protection requirements of the above EU directives, and the manufacturer has applied the following standards.

  • Page 3: Important Information

    Product revision • Because we at Digital Projection continually strive to improve our products, we may change specifications and designs, and add new features without prior notice. Projectors built prior to this revision of the User Manual may therefore not include all the features described.

  • Page 4: General Precautions

    TITAN sx+-500 Important Information Digital Projection User Manual General precautions Notes Do not open the cabinet. There are no user serviceable parts inside. Use only the power cable provided. Ensure that the power outlet includes a Ground connection, as this equipment MUST be earthed.

  • Page 5: Installation Precautions

    TITAN sx+-500 Digital Projection User Manual Important Information Installation precautions Notes Connect the LAN cable only to a computer LAN connection. Other similar connectors may have a dangerously high voltage source. The projector must be installed only by suitably qualified personnel, in accordance with local building codes.

  • Page 6: Operation And Configuration Precautions

    Electronic Equipment. Our products are designed with reuse, recycling and recovery of all components in mind. To this end, at end of life, your projector may be returned to Digital Projection Ltd or its agent so that the environmental impact can be minimised.

  • Page 7: Digital Projection Contact Details

    TITAN sx+-500 Digital Projection User Manual Important Information Digital Projection Contact details Notes Digital Projection Limited Greenside Way, Middleton, Manchester M24 1XX, UK. Registered in England No. 2207264, Registered Office: as above Tel: +44 (0) 161 947 3300 Fax:+44 (0) 161 684 7674 Email enquiries@digitalprojection.co.uk, service@digitalprojection.co.uk...
  • Page 8 TITAN sx+-500 Important Information Digital Projection User Manual Rev C March 2008 page vi...

  • Page 9: Table Of Contents

    Compliance with international standards ...............iv Noise ................................ iv RF Interference ............................iv European Waste Electrical and Electronic Equipment (WEEE) Directive .......... iv Digital Projection Contact details ..................v 1. Introduction What’s in the box? ......................1.2 Key features of the projector ..................1.3 Getting to know the projector ..................1.4...
  • Page 10 TITAN sx+-500 Contents Digital Projection User Manual 3. Getting started Switching the projector on .....................3.2 Selecting an input or test pattern ..................3.2 Input ............................... 3.2 Adjusting the lens ......................3.3 Focus ..............................3.3 Zoom ..............................3.3 Shift ................................ 3.3 Adjusting the projected image ..................3.4 Picture settings .............................
  • Page 11 On Screen Display ..........................4.38 Password ............................. 4.39 Communication ........................... 4.40 Network ..............................4.41 Restore Defaults ..........................4.46 Information menu......................4.47 Projector Information .......................... 4.47 Source Information ..........................4.47 Digital Projection Information ......................4.48 continued Rev C March 2008 page ix...
  • Page 12 TITAN sx+-500 Contents Digital Projection User Manual 5. Userware 6. Maintenance Changing the lamp......................6.2 Changing the air filter .....................6.3 Cleaning ...........................6.4 Projector ..............................6.4 Lens ................................ 6.4 Lamp module ............................6.4 7. Appendix Troubleshooting ......................7.2 Specifications ........................7.4 Part numbers ............................7.4 Optical ..............................
  • Page 13 TITAN sx+-500 Digital Projection User Manual Contents Rev C March 2008 page xi...
  • Page 14 TITAN sx+-500 Contents Digital Projection User Manual Rev C March 2008 page xii...

  • Page 15: Introduction

    1. Introduction Contents Introduction What’s in the box?........................1.2 Key features of the projector....................1.3 Getting to know the projector ....................1.4 Front panel, – lens and power ........................1.4 Rear panel – lamp and air filter ........................1.4 Side panel – connection and control ......................1.5 Rev C March 2008...

  • Page 16: What's In The Box

    TITAN sx+-500 1. Introduction Digital Projection User Manual What’s in the box? Notes • Make sure your box contains everything listed. If any pieces are missing, contact your dealer. Lenses are optional. Order • You should save the original box and packing materials, in case you ever need to lenses from your Digital ship your Projector.

  • Page 17: Key Features Of The Projector

    Digital Projection International, Texas Instruments' first DLP™ partner and the original innovator of the 3-chip DLP™ projector, proudly introduces the Titan sx+- 500. Incredibly bright, high resolution and high in contrast, the Titan sx+-500 offers a radically new electronics configuration ideally suited for the staging and large-venue permanent installation markets.

  • Page 18: Getting To Know The Projector

    TITAN sx+-500 1. Introduction Digital Projection User Manual Getting to know the projector Notes Front panel, – lens and power Air outlet For more detailed information about lenses, see section 2. Installation Air inlet - around lens Front Infra-red window...

  • Page 19: Side Panel - Connection And Control

    TITAN sx+-500 Digital Projection User Manual 1. Introduction Side panel – connection and control Notes Control panel For information about how to connect the projector, see Connecting the projector in section 2. Installation, and Connections in section 7. Appendix. For information about how to use the control panel, see section 4.
  • Page 20 TITAN sx+-500 1. Introduction Digital Projection User Manual Rev C March 2008 page 1.6...

  • Page 21: Installation

    2. Installation Contents Installation Screen requirements .......................2.2 Aspect ratio ..............................2.2 Fitting the image to the DMD ........................2.2 Images displayed full height ......................... 2.2 Images displayed full width .......................... 2.2 Diagonal screen sizes ..........................2.3 Fitting the image to the screen ........................2.4 Positioning the screen and projector ......................

  • Page 22: Screen Requirements

    TITAN sx+-500 2. Installation Digital Projection User Manual Screen requirements Notes Aspect ratio Fitting the image to the DMD If the source image supplied to the projector is smaller than 1400 x 1050 pixels, then the image will not fill the DMD. The following example shows how a number of common formats may be displayed.

  • Page 23: Diagonal Screen Sizes

    TITAN sx+-500 Digital Projection User Manual 2. Installation Diagonal screen sizes Notes Screen sizes are sometimes specified by their diagonal size (D) in inches. When dealing with large screens and projection distances at different aspect ratios, it is more convenient to measure screen width (W) and height (H).

  • Page 24: Fitting The Image To The Screen

    TITAN sx+-500 2. Installation Digital Projection User Manual Fitting the image to the screen Notes It is important that your screen is of sufficient height and width to display images at all the aspect ratios you are planning to use.

  • Page 25: Positioning The Screen And Projector

    TITAN sx+-500 Digital Projection User Manual 2. Installation Positioning the screen and projector Notes For optimum viewing, the screen should be a flat surface perpendicular to the floor. The bottom of the screen should be 1.2m (4 feet) above the floor and the front row The projector should be of the audience should not have to look up more than 30°...

  • Page 26: Choosing A Lens

    TITAN sx+-500 2. Installation Digital Projection User Manual Choosing a lens Notes A number of lenses are available for use with the projector. Which lens you choose will depend on the screen size, image aspect ratio and projection distance. If you are simply connecting the output of a camera or computer directly to the projector, then the image size (in pixels) may well be fixed.

  • Page 27: Lens Chart

    TITAN sx+-500 Digital Projection User Manual 2. Installation Lens chart Notes Use the chart below to choose which lens best suits your application. For a 5:4 full height image, example measuring 1313 x 1050 pixels: • For a screen width of 12m at a distance of 35m, the 2.77 - 4.51: 1 zoom lens A Throw ratio factor (TRF) of would be best suited.

  • Page 28: Method Two: Choosing A Lens By Calculation

    TITAN sx+-500 2. Installation Digital Projection User Manual Method two: Choosing a lens by calculation Notes For any screen size not listed above, or if you need to be more precise, then use the calculations below. The Throw ratio for a particular •...

  • Page 29: Useful Lens Calculations

    TITAN sx+-500 Digital Projection User Manual 2. Installation Useful lens calculations Notes The Throw ratio for a particular The following lens calculations may be useful: lens is fixed, but assumes that the image fills the width of the DMD. Throw ratio =...

  • Page 30: Fitting The Lens

    TITAN sx+-500 2. Installation Digital Projection User Manual Fitting the lens Notes • Turn the lens release lever anti-clockwise so that it is pointing upwards, to open the lock. • Remove the rear lens cap from the lens. Make sure the rear lens cap is •...

  • Page 31: Shifting The Image

    TITAN sx+-500 Digital Projection User Manual 2. Installation Shifting the image Notes For more information on using The normal position for the projector is at the centre of the screen. However, you the Lens shift feature, see can set the projector above or below the centre, or to one side, and adjust the image section 4.

  • Page 32: Mounting The Projector

    TITAN sx+-500 2. Installation Digital Projection User Manual Mounting the projector Notes The projector is designed to be used on a flat surface, but the optional rigging frame will allow it to be suspended from a lighting truss or rigging. The four adjustable feet...

  • Page 33: Adjusting The Rigging Frame

    TITAN sx+-500 Digital Projection User Manual 2. Installation Adjusting the rigging frame Notes Coarse adjustment of projector level should be made by adjusting the length of the Before suspending the supporting wires or chains, or by adjusting the position of the truss or rigging. Once...

  • Page 34: Stacking Projectors

    TITAN sx+-500 2. Installation Digital Projection User Manual Stacking projectors Notes The rigging frame is capable of supporting the weight of up to two other projectors, using the built-in frame couplings. The projectors can be stacked on top of each other, or suspended below each other.

  • Page 35: Connecting The Projector

    TITAN sx+-500 Digital Projection User Manual 2. Installation Connecting the projector Notes Input Control connection panel connection panel Signal Inputs The following inputs are available: 3. DVI 4. SDI 2. RGB2 For more information on selecting an input source, see section 4.

  • Page 36: Control Connection Examples

    TITAN sx+-500 2. Installation Digital Projection User Manual Control connection examples Notes LAN connection For more information about pin All of the projector’s features can be controlled via a LAN connection, using a connections and control codes standard internet browser package such as Internet Explorer.

  • Page 37: Power Connection

    TITAN sx+-500 Digital Projection User Manual 2. Installation Power connection Notes When mains power is first applied, the projector will perform a self-test, then go into Standby mode. The Power indicator on the control panel will show amber until the POWER Use only the power cable on the remote control or the keypad, is pressed for 3 seconds.
  • Page 38 TITAN sx+-500 2. Installation Digital Projection User Manual Rev C March 2008 page 2.18...

  • Page 39: Rev C March 2008

    3. Getting started Contents Getting started Switching the projector on .....................3.2 Selecting an input or test pattern ..................3.2 Input ................................. 3.2 Adjusting the lens ........................3.3 Focus ................................3.3 Zoom ................................3.3 Shift .................................. 3.3 Adjusting the projected image ....................3.4 Picture settings ............................... 3.4 Geometry settings ............................

  • Page 40: Switching The Projector On

    TITAN sx+-500 3. Getting started Digital Projection User Manual Switching the projector on Notes • Connect the power cable between the mains supply and the projector. For more information about connecting the power cable, see Power Connections, in Section 2. Installation.

  • Page 41: Adjusting The Lens

    TITAN sx+-500 Digital Projection User Manual 3. Getting started Adjusting the lens Notes For more detailed information Focus about: - using the control keys on the • Press followed by to adjust the focus. remote control or keypad, - using the menus,...

  • Page 42: Adjusting The Projected Image

    TITAN sx+-500 3. Getting started Digital Projection User Manual Adjusting the projected image Notes Picture settings • Press a key, followed by to adjust these picture settings: The Saturation control is available for Composite, S- Brightness Video and Component inputs only.

  • Page 43: Controlling The Projector

    4. Controlling the projector Contents 4. Controlling the projector Overview ..........................4.4 Controlling the projector ..........................4.4 Input modes and settings ..........................4.5 Input mode detection ............................ 4.5 Mode library and mode history ........................4.5 Input presets ..............................4.6 Indicators ..........................4.7 Input status indicators ............................
  • Page 44 TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Using the menus ........................4.15 Navigating menus and submenus ....................... 4.15 Menu controls ..............................4.17 Input menu ..........................4.18 Input Source ..............................4.18 Presets ................................4.19 Recall Presets ............................4.19 Save Presets ..............................
  • Page 45 LAN Subnet Mask ............................4.43 LAN Gateway Mask ........................... 4.44 Channel ..............................4.45 SSID ................................4.45 Restore Defaults ............................4.46 Information menu ........................4.47 Projector Information ............................ 4.47 Source Information ............................4.47 Digital Projection Information ........................4.48 Rev C March 2008 page 4.3...

  • Page 46: Overview

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Overview Notes Controlling the projector The projector can be controlled from: • the remote control • the keypad • the RS232 input • the Ethernet input For more information about controlling the projector using the RS232 and Ethernet inputs, see Remote communications protocol in section 7.

  • Page 47: Input Modes And Settings

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Input modes and settings Notes Input mode detection The projector can automatically detect the following parameters from the incoming video signal: • line frequency • frame rate • interlace / progressive...

  • Page 48: Input Presets

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Any subsequent changes that you make to the modal settings will be saved in the Notes mode history, with the input mode. Mode Mode history library defaults NTSC NTSC modal...

  • Page 49: Indicators

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Indicators Notes Input status indicators 1. RGB1 4. SDI 3. DVI There are more indicators on the Control panel, and these are 2. RGB2 described on the next page. 6. S-Video 7.

  • Page 50: The Control Panel

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual The control panel Notes Many features are controlled Keypad layout from the menus using the menu navigation keys on the remote The controls on the keypad are identical to those at the top of the remote control, control or keypad.

  • Page 51: The Remote Control

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector The remote control Notes Many features are controlled Layout from the menus using the menu navigation keys on the remote control or keypad. For more information about Transmit using the menus, see later in indicator this section, Using the menus.

  • Page 52: Using The Control Keys

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Using the control keys Notes Power • Press POWER and hold for 3 seconds, to switch the projector ON. • Press POWER and hold for 3 seconds, to switch the projector into STANDBY mode.

  • Page 53: Auto-Detect Input Mode

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Auto-detect input mode Notes For more information about • Press to force the projector to re-detect the input mode input mode detection, see (see Input modes and settings, earlier in this section).

  • Page 54: Input Presets

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Input Presets Notes Recall • To recall a set of modal settings that have been saved, press and hold For more information about whilst pressing the lettered key A – S.

  • Page 55: Red, Green And Blue

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Red, Green and Blue Notes The red, green and blue keys • Press to switch the red, green or blue components OFF are disabled when the OSD is or ON.

  • Page 56: Magnify And Pan

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Magnify and pan Notes The magnify feature utilises a • Press Magnify MAGNIFY digital zoom. Used with the pan control, this can be used to: followed by to adjust the size of the picture.

  • Page 57: Using The Menus

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Using the menus Notes Some menu controls can be Navigating menus and submenus accessed directly using the control keys (see earlier in this When the menus are in use and the OSD is ON, the top level menu headings are section).
  • Page 58 TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Notes Press to open the menu. The blue highlight moves to the first item in the menu, which may be submenu, for example the Projector Setup submenu. Setup menu •...

  • Page 59: Menu Controls

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Menu controls Notes Some menus have controls, as shown in the examples below. Some menus items may be greyed out - unavailable due to the effect of settings made in other menus, or due to the type of input signal.

  • Page 60: Input Menu

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Input menu Notes Some menu controls can be To return to the main menu, press up to three times. accessed directly using the control keys (see earlier in this section).

  • Page 61: Presets

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Input menu continued Notes Presets Some menu controls can be accessed directly using the Sixteen sets of parameters can be saved and recalled (A – S). The parameters control keys (see earlier in this saved for each Preset are: section).
  • Page 62 TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Input menu continued Notes Save Presets Some menu controls can be accessed directly using the • Press to select Save Preset. control keys (see earlier in this section). Press to open the Save Presets A ~ H submenu.

  • Page 63: Picture Menu

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Picture menu Notes Some menu controls can be To return to the main menu, press up to three times. accessed directly using the control keys (see earlier in this section).

  • Page 64: Gamma Correction

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Picture menu continued Notes Gamma Correction Video recordings are often supplied with a gamma adjustment applied. The projector’s gamma adjustment can be used to correct for this. • Press to select Gamma.

  • Page 65: Aspect Ratio

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Picture menu continued Notes Aspect Ratio Aspect Ratio selection can be • Press to select Aspect Ratio. found in both the Picture and Geometry menus. Press to select from: Fill This will best fit the incoming source to fill either the height or width without changing the aspect ratio of the source.

  • Page 66: Geometry Menu

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Geometry menu Notes Some menu controls can be To return to the main menu, press up to three times. accessed directly using the control keys (see earlier in this section).

  • Page 67: User Horizontal Aspect Ratio

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Geometry menu continued Notes User Horizontal Aspect Ratio • Press to select User H Aspect. Horizontal and Vertical Press to adjust the slider (internal number – adjust to fit). Aspect Ratio adjustments are...

  • Page 68: Resolution

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Geometry menu continued Notes Resolution • Press to select Resolution. Press to open the Resolution submenu. Input RESOLUTION Automatic Input Detection Picture Geometry Menu Input Standard Geometry Resolution Total H Samples...

  • Page 69: Blanking

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Geometry menu continued Notes When Input Detection is set to Custom: • Press to select one of the adjustment sliders. Press to adjust the slider to match the resolution of the incoming video signal.

  • Page 70: Colour Menu

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Colour menu Notes To return to the main menu, press up to three times. When using the menus, press to hide or From the main menu: reveal the On-Screen-Display. •...

  • Page 71: Colour Mode

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Colour menu continued Notes Colour Mode • Press to select Colour Mode. Read the notes on Colour and Global Colourimetry earlier in Press to select from: this section before making...

  • Page 72: Trim

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Colour menu continued Notes Trim The Trim submenu is available • Press to select Trim. only if Global Colour Mode is selected. Press to open the Trim submenu. Colour Menu...

  • Page 73: Setup Menu

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Setup menu Notes To return to the main menu, press up to three times. From the main menu: When using the menus, press • Press until Setup is highlighted. to hide or Press to open the Setup menu.

  • Page 74: Projector

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Setup menu, continued Notes Projector • Press to select Projector. Press to open the Projector submenu. Setup Menu Projector Orientation • Press to select Orientation. Press to select from: Desktop Front...
  • Page 75 TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Setup menu, Projector continued Notes Keystone Used to correct for distortion caused by the projector being mounted higher or lower than the screen. • Press to select Keystone. Press to adjust the slider (-128 to +127).

  • Page 76: Global Colourimetry

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Setup menu continued Notes Global Colourimetry • Press to select Global Colourimetry. Press to open the Global Colourimetry submenu. Setup Menu Global Colourimetry Some menu items may be greyed out - unavailable due to...
  • Page 77 TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Setup menu, Global Colourimetry continued Notes Colour Mode • Press to select Colour Mode. Read the notes on Colour and Press to select from: Global Colourimetry earlier in this section before making...

  • Page 78: Setup Menu

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Setup menu, continued Notes Lamp • Press to select Lamp. Press to open the Lamp submenu. The middle row shows the current lamp setting. Setup Menu Lamp Change Lamp Setting •...

  • Page 79: Lamp Power

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Setup menu, Lamp continued Notes Lamp Power • Press to select the Lamp Power setting. Press to adjust the Lamp Power from: 80 to 100% in 1% steps Lamp Mode •...

  • Page 80: On Screen Display

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Setup menu continued Notes On Screen Display • Press to select On Screen Display. Press to open the On Screen Display submenu. Setup Menu On Screen Display OSD Position •...

  • Page 81: Password

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Setup menu continued Notes Password Entry to the password protected area is available to authorised service personel only. • Press to select Password. Press to open the Password control box.

  • Page 82: Communication

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Setup menu continued Notes Communication • Press to select Communication. Press to open the Communication submenu. Setup Menu Communication Projector Address The projector and the remote control need to be set to matching addresses. Read...

  • Page 83: Network

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Setup menu continued Notes Network • Press to select Network. Press to open the Network submenu. Input NETWORK 31-FE-A5-81-20-83 LAN MAC Address Picture Connection Geometry Wired Colour DHCP Setup Menu...

  • Page 84: Dhcp

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Setup menu, Network continued Notes DHCP • Press to select DHCP Press to open the DHCP control box. Press to select from: Press to apply the new DHCP setting. LAN IP Address •...

  • Page 85: Lan Subnet Mask

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Setup menu, Network continued Notes LAN Subnet Mask • Press to select LAN Subnet LAN IP Subnet cannot be Press to open the LAN Subnet control box. changed if DHCP is set to ON.

  • Page 86: Lan Gateway Mask

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Setup menu, Network continued Notes LAN Gateway Mask • Press to select LAN Gateway LAN IP Gateway cannot be Press to open the LAN IP Address control box. changed if DHCP is set to ON.

  • Page 87: Channel

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Setup menu, Network continued Notes Channel • Press to select Channel. The Channel setting is not Press to open the Channel control box. available if Connection is set to Wired.

  • Page 88: Restore Defaults

    TITAN sx+-500 4. Controlling the projector Digital Projection User Manual Setup menu, continued Notes Restore Defaults • Press to select Restore Defaults. Press Restore Defaults will restore all settings to factory The following message will be displayed. defaults. If you are not sure this is...

  • Page 89: Information Menu

    TITAN sx+-500 Digital Projection User Manual 4. Controlling the projector Information menu Notes To return to the main menu, press up to three times. When using the menus, press to hide or From the main menu: reveal the On-Screen-Display. • Press until Information is highlighted.

  • Page 90: Digital Projection Information

    User Manual Information menu continued Notes Digital Projection Information • When using the menus, press Press to select Digital Projection. to hide or Press to see the DP Information screen. reveal the On-Screen-Display. Information Menu DP Contact Information Rev C March 2008 page 4.48...
  • Page 91 5. Userware Contents Userware Rev C March 2008...
  • Page 92 TITAN 5. Userware Digital Projection User Manual Rev C March 2008 page 5.2...
  • Page 93 6. Maintenance Contents Maintenance Changing the lamp ........................6.2 Changing the air filter ......................6.3 Cleaning ...........................6.4 Projector ................................6.4 Lens .................................. 6.4 Lamp module ..............................6.4 Rev C March 2008...

  • Page 94: Maintenance

    TITAN sx+-500 6. Maintenance Digital Projection User Manual Changing the lamp Notes • Turn the power OFF and allow the lamp to cool for 5 minutes. Always allow the lamp to cool • Unscrew the three door screws, and detach the rear door - the door is tethered, for 5 minutes before: so cannot be removed completely.

  • Page 95: Changing The Air Filter

    TITAN sx+-500 Digital Projection User Manual 6. Maintenance Changing the air filter Notes • Turn the power OFF and allow the lamp to cool for 5 minutes. Always allow the lamp to cool • Unscrew the three door screws, and remove the rear door.

  • Page 96: Cleaning

    TITAN sx+-500 6. Maintenance Digital Projection User Manual Cleaning Notes Turn the projector off before cleaning. Projector Never use strong detergents or solvents such as alcohol Clean the cabinet periodically with a damp cloth. If heavily soiled, use a mild or thinners to clean the detergent.
  • Page 97 7. Appendix Contents Appendix Troubleshooting ........................7.2 Specifications ..........................7.4 Part numbers ..............................7.4 Optical ................................7.4 Electrical ................................7.5 Physical ................................7.5 Lens Data ................................. 7.6 Dimensions ..........................7.8 Input modes supported ......................7.9 Input connections .........................7.10 1. RGB1 input ..............................7.10 2.

  • Page 98: Appendix

    TITAN sx+-500 7. Appendix Digital Projection User Manual Troubleshooting Problem Possible solutions The projector will not power up. Check that the mains plug is plugged in and that the mains supply is switched on. Check any external fuses or breakers.
  • Page 99 See this section 7. Appendix, Connections Check that the correct control codes are being used. See Serial communications protocol (available from Digital Projection) Projector does not respond to control If you are using a cable, check that the cable is connected properly at both ends, commands from the remote control.

  • Page 100: Specifications

    TITAN sx+-500 7. Appendix Digital Projection User Manual Specifications Part numbers Projector 105-925 Rigging frame 104-923 Power cable 10A, Europe 102-163 Power cable 13A, North America 102-165 Power cable 10A, United Kingdom 102-180 Remote control 105-023 4x AAA batteries 105-922...

  • Page 101: Electrical

    TITAN sx+-500 Digital Projection User Manual 7. Appendix Electrical Inputs RGB1, RGB2, DVI, SDI, Composite Video, S-Video, Component Pixel clock up to 165MHz Control inputs 1 x LAN 1 x wifi LAN 1 x RS232 serial: 19200 baud, 8 bits, 1 stop bit, no parity...

  • Page 102: Lens Data

    TITAN sx+-500 7. Appendix Digital Projection User Manual Lens Data 105-607 105-608 105-609 105-610 throw ratio 0.73 : 1 fixed 1.2 : 1 fixed 1.2 : 1 fixed 1.5 - 2.02 : 1 zoom full DMD image width 1.5m - 4.4m 2.5 - 12.4m...
  • Page 103 TITAN sx+-500 Digital Projection User Manual 7. Appendix 105-611 105-612 105-613 throw ratio 2.02 - 2.77 : 1 zoom 2.77 - 4.51 : 1 zoom 4.51 - 7.53 : 1 zoom full DMD image width 1.4 - 11.9m 2 - 16.3m 1.7 - 17.7m...

  • Page 104: Dimensions

    TITAN sx+-500 7. Appendix Digital Projection User Manual Dimensions All dimensions in mm unless otherwise stated Rev C March 2008 page 7.8...

  • Page 105: Input Modes Supported

    TITAN sx+-500 Digital Projection User Manual 7. Appendix Input modes supported Signal Resolution Refresh Total Horizontal Rate number of Frequency ( Hz ) lines (KHz) SDTV 480i 720 x 480 15.73 576i 720 x 576 15.63 HDTV 480p 720 x 480 31.51...

  • Page 106: Input Connections

    TITAN sx+-500 7. Appendix Digital Projection User Manual Input connections Notes 1. RGB1 input 5 x 75 ohm BNC Used for computer, progressive video and analog HD video. RGsB RGBS RGBHV YCrCb Pr/Cr G + Sync Pb/Cb Sync H Sync V Sync 2.

  • Page 107: Dvi-D Input

    TITAN sx+-500 Digital Projection User Manual 7. Appendix 3. DVI-D input Notes 24 way D-type connector TMDS Data 2- pin view of female connector TMDS Data 2+ TMDS Data 2 Shield unused unused DDC Clock DDC Data unused TMDS Data 1-...

  • Page 108: Sdi Input

    TITAN sx+-500 7. Appendix Digital Projection User Manual 4. SDI input Notes 1 x 75 ohm BNC SMPTE 292 / HD-SDI signals are very high speed digital signals which require better quality coaxial cable than conventional analogue video. The data rate is 1.5 Gigabits per second.

  • Page 109: Control Connections

    TITAN sx+-500 Digital Projection User Manual 7. Appendix Control connections Notes Wired remote control connection Note that plugging in the remote 3.5mm mini jack control cable will disable the Sleeve infra-red. Power Ring Signal Sleeve Ground Ring LAN connections TCP Port number...

  • Page 110: Serial Control Input

    TITAN sx+-500 7. Appendix Digital Projection User Manual Serial control input Notes unused Received Data (RX) The projector is a DTE, so use: Transmitted Data (TX) • pin view of female connector unused a straight cable to connect to a...

  • Page 111: Remote Communications Protocol

    For full details of all the commands relate to the projector’s hand held remote control only. Operation commands and Enhanced commands, contact Digital Projection at one of the Message Structure addresses printed near the front of this manual, and ask for a...

  • Page 112: Operation Messages

    TITAN sx+-500 7. Appendix Digital Projection User Manual Operation Messages Operation messages are constructed using the following format: Header Type Size Oper’n Operation Reserved type 2 bytes 1 byte 2 bytes 2 bytes 1 byte 2 bytes 2 bytes Data...

  • Page 113: Enhanced Messages

    TITAN sx+-500 Digital Projection User Manual 7. Appendix Enhanced Messages Enhanced messages are constructed using the following format: Header Type Size Data type Data length (n) 2 bytes 1 byte 2 bytes 2 bytes 2 bytes 2 bytes Data Byte # 1...

  • Page 114: Operation Command Examples

    TITAN sx+-500 7. Appendix Digital Projection User Manual Operation Command examples Notes All operation commands are located at bytes 9 &10. Spaces in example messages are for visual clarity and should All values are located at bytes 17 & 18 unless otherwise indicated not be sent as part of the message.

  • Page 115: Source (3702)

    TITAN sx+-500 Digital Projection User Manual 7. Appendix Source (3702) Notes Spaces in example messages Projector source select are for visual clarity and should Value not be sent as part of the message. RGB1 In the example messages the RGB2 CRC is set to 5858h.

  • Page 116: Brightness (E502)

    TITAN sx+-500 7. Appendix Digital Projection User Manual Brightness (E502) Notes Spaces in example messages Adjusts Brightness are for visual clarity and should -128 — +127 (00h - FFh) Range: not be sent as part of the message. Centre (0):...

  • Page 117: Contrast (E602)

    TITAN sx+-500 Digital Projection User Manual 7. Appendix Contrast (E602) Notes Spaces in example messages Adjusts Contrast are for visual clarity and should -128 — +127 (00h - FFh) Range: not be sent as part of the message. Centre (0):...

  • Page 118: Shutter (Cf02)

    TITAN sx+-500 7. Appendix Digital Projection User Manual Shutter (CF02) Notes Spaces in example messages Closes and opens shutter are for visual clarity and should Target Value not be sent as part of the (Set) (Get) message. Shutter Close In the example messages the CRC is set to 5858h.

  • Page 119: Quick Reference Chart

    TITAN sx+-500 Digital Projection User Manual 7. Appendix Quick Reference chart Rev C March 2008 page 7.23...
  • Page 120 TITAN sx+-500 7. Appendix Digital Projection User Manual Rev C March 2008 page 7.24...

Table of Contents
