For important information about how to control the projector when Input 8 is being used, see the final pages of Section 4.
Digital Projection Digital Projection
TITAN sx+ 3D, Dual 3D, Ultra Contrast TITAN sx+ 3D, Dual 3D, Ultra Contrast

Using the control keys

Power

• Press POWER and hold for 3 seconds, to switch the projector ON.
• Press POWER and hold for 3 seconds, to switch the projector OFF.

Shutter

• Press SHUTTER
• Press SHUTTER

On-Screen-Display

• Press OSD to switch the On-Screen-Display OFF.
This includes ALL menus, controls and on-screen messages.
• Press OSD to switch the On-Screen-Display ON.

Focus

• Press followed by
When adjustment is finished, press

Zoom

• Press followed by
When adjustment is finished, press

Shift

• Press followed by
right.
When adjustment is finished, press
Rev A August 2009 Rev A August 2009
to OPEN the shutter.
to CLOSE the shutter.
and to adjust the focus.
.
and to adjust the zoom.
.
, , or to shift the lens up, down, left or
.
User Manual User Manual
Closing the shutter produces
a better black than simply
removing the signal, as the
light source will be completely
blocked by the shutter blade.
When the OSD is OFF:
- all menu navigation keys are
disabled.
- keys such as
(brightness) will still function,
but the slider bars will not be
visible on screen.
When any of the three Lens
adjustment keys is pressed, the
blue Transmit indicator on the
remote control will light for 10
seconds:
- after 10 seconds, if no
adjustment has been made,
the indicator will go out and
the Lens adjustment key must
be pressed again to resume
adjustment.
- to end the adjustment before
10 seconds has elapsed, press
the
- all other adjustments will
be locked out until the Lens
adjustment is ended.
For more information about the
amount of lens shift available,
see section 2. Installation.
4. Controlling the projector 4. Controlling the projector
Notes
BrI
key.
