Key Features Of The Projector - Digital Projection TITAN sx+ 3D Dual 3D Ultra Contrast User Manual

Digital Projection
TITAN sx+ 3D, Dual 3D, Ultra Contrast

Key features of the projector

Congratulations on your purchase of the Digital Projection Titan sx+-3D/FastFrame
projector.
Digital Projection International, Texas Instruments' first DLP™ partner and the
original innovator of the 3-chip DLP™ projector, proudly introduces the Titan sx+.
Titan 3D projectors are the perfect imaging solution for vital immersive applications,
including military, scientific and medical applications, product engineering,
commercial cinema and theme parks. In addition, DP's new FastFrame™
technology is a revolutionary combination of hardware and firmware that reduces
the artifact and image blur associated with rapidly moving displayed content.
The Titan sx+ harnesses the power of the Texas Instruments' 1400 x 1050 pixel
DMD's™. Along side the LIGHTNING and HIGHlite Pro, the Titan sx+ is to set new
standards for Staging and destined to be the first choice of professionals who stage
prestigious events such as the Grammy® Awards and the Oscars®. With a contrast
of up to 4000:1 and awe-inspiring brightness of up to 9000 lumens, the Titan sx+
is unmatched for applications as diverse as world class staged events, commercial
entertainment, major outdoor venues, large-scale simulation, gaming and houses of
worship.
Key Features
High resolution, large venue 3D projector
•
• Applications: Large Screen; Fixed install and Rental
• sx+ 3D:
sx+ 3D Ultra Contrast:
sx+ Dual 3D:
sx+ Dual 3D Ultra Contrast:
• Standard
Ultra Contrast:
• 1400 x 1050 resolution
• Precision mechanical design ensuring maximum amount of light from lamp
housing reaches optics, without any operator adjustment
• Single:
Dual:
• Compact size, light weight - 31 kg (68 lbs)
• Intelligent motorised lens mount
• Optional Rigging frame with Quick-lock stack system
• Ruggedised robust metal case
• Floating chassis - 3 point pitch & roll adjustment for accurate alignment
• LAN & RS232 connection for network operation
• Eight selectable Digital and Analogue Video inputs for display of the latest as
well as legacy video standards.
• DVI, SD and HD SDI, RGBHV, Component, S-Video, Composite all as standard
• Wi-fi connection wireless remote control
• IR/cable remote control for easy setup
• LAN operation using control codes or Integrated Userware
Rev A August 2009
4500 ANSI lumens ±10%
2500 ANSI lumens ±10%
9000 ANSI lumens ±10%
4500 ANSI lumens ±10%
Contrast 2000:1 ±10%
Contrast 4000:1 ±10%
580W single phase, 100-240VAC ±10%
910W single phase, 100-240VAC ±10%
User Manual 1. Introduction
Notes
Page 1.3
