EPSON AcuLaser CX11/CX11F

AVAILABLE PAPER BY FEEDER

Table 1-19. Available Paper by Feeder
Standar Plain
Paper Feeder
d paper paper
MP tray
500-sheet
cassette
Note : Paper feed and image quality is guaranteed.
: Paper feed and printing is possible. However, this is limited to types of paper
for general applications.
Image quality is not guaranteed.
X : Feed is not possible.
Special paper
Postcar Thick Envelo
OHP Label
d paper pes
X X X X X

PRINTING AREA

Maximum printable area
216.00 mm (width) x 355.60 mm (length)
NOTE: Continuous printing beyond the guaranteed printing area (border 4mm)
Coated
causes soiling inside the mechanism.
paper
Printable area
The minimum left, right, top and bottom margins are 4 mm for any type of paper.
X
For envelop, however, left and right margins should be 6 mm.
4mm 4mm
Printable area
Figure 1-4. Printable Area
