Texas Instruments TMS320C6474 Manual page 90

TMS320C6474
SPRS552F – OCTOBER 2008 – REVISED JULY 2010
HEX ADDRESS
02A0 225C
02A0 2260
02A0 2264
02A0 2268
02A0 226C
02A0 2270
02A0 2274
02A0 2278
02A0 227C
02A0 2280
02A0 2284
02A0 2288
02A0 228C
02A0 2290
02A0 2294
02A0 2298 - 02A0 23FF
02A0 2400
02A0 2404
02A0 2408
02A0 240C
02A0 2410
02A0 2414
02A0 2418
02A0 241C
02A0 2420
02A0 2424
02A0 2428
02A0 242C
02A0 2430
02A0 2434
02A0 2438
02A0 243C
02A0 2440
02A0 2444
02A0 2448 - 02A0 244C
02A0 2450
02A0 2454
02A0 2458
02A0 245C
02A0 2460
02A0 2464
02A0 2468
02A0 246C
02A0 2470
02A0 2474
02A0 2478
90 Peripheral Information and Electrical Specifications
Table 7-5. EDMA3 Registers (continued)
ACRONYM
IECRH Interrupt Enable Clear Register High
IESR Interrupt Enable Set Register
IESRH Interrupt Enable Set Register High
IPR Interrupt Pending Register
IPRH Interrupt Pending Register High
ICR Interrupt Clear Register
ICRH Interrupt Clear Register High
IEVAL Interrupt Evaluate Register
- Reserved
QER QDMA Event Register
QEER QDMA Event Enable Register
QEECR QDMA Event Enable Clear Register
QEESR QDMA Event Enable Set Register
QSER QDMA Secondary Event Register
QSECR QDMA Secondary Event Clear Register
- Reserved
Shadow Region 2 Channel Registers
ER Event Register
ERH Event Register High
ECR Event Clear Register
ECRH Event Clear Register High
ESR Event Set Register
ESRH Event Set Register High
CER Chained Event Register
CERH Chained Event Register Hig
EER Event Enable Register
EERH Event Enable Register High
EECR Event Enable Clear Register
EECRH Event Enable Clear Register High
EESR Event Enable Set Register
EESRH Event Enable Set Register High
SER Secondary Event Register
SERH Secondary Event Register High
SECR Secondary Event Clear Register
SECRH Secondary Event Clear Register High
- Reserved
IER Interrupt Enable Register
IERH Interrupt Enable Register High
IECR Interrupt Enable Clear Register
IECRH Interrupt Enable Clear Register High
IESR Interrupt Enable Set Register
IESRH Interrupt Enable Set Register High
IPR Interrupt Pending Register
IPRH Interrupt Pending Register High
ICR Interrupt Clear Register
ICRH Interrupt Clear Register High
IEVAL Interrupt Evaluate Register
Submit Documentation Feedback
Product Folder Link(s)
REGISTER NAME
Copyright © 2008–2010, Texas Instruments Incorporated
:TMS320C6474
www.ti.com
