Table 7-12. EDMA3 Transfer Controller 5 Registers (continued)
HEX ADDRESS RANGE
02A4 8244
02A4 8248
02A4 824C
02A4 8250
02A4 8254
02A4 8258
02A4 825C
02A4 8260
02A4 8264 - 02A4 827C
02A4 8280
02A4 8284
02A4 8288
02A4 828C - 02A4 82FC
02A4 8300
02A4 8304
02A4 8308
02A4 830C
02A4 8310
02A4 8314
02A4 8318 - 02A4 833C
02A4 8340
02A4 8344
02A4 8348
02A4 834C
02A4 8350
02A4 8354
02A4 8358 - 02A4 837C
02A4 8380
02A4 8384
02A4 8388
02A4 838C
02A4 8390
02A4 8394
02A4 8398 - 02A4 83BC
02A4 83C0
02A4 83C4
02A4 83C8
02A4 83CC
02A4 83D0
02A4 83D4
02A4 83D8 - 02A4 FFFC
Copyright © 2008–2010, Texas Instruments Incorporated
ACRONYM
REGISTER NAME
SASRC
Source Active Source Address Register
SACNT
Source Active Count Register
SADST
Source Active Destination Address Register
SABIDX
Source Active Source B-Index Register
SAMPPRXY
Source Active Memory Protection Proxy Register
SACNTRLD
Source Active Count Reload Register
SASRCBREF
Source Active Source Address B-Reference Register
SADSTBREF
Source Active Destination Address B-Reference Register
-
Reserved
DFCNTRLD
Destination FIFO Set Count Reload
DFSRCBREF
Destination FIFO Set Destination Address B Reference Register
DFDSTBREF
Destination FIFO Set Destination Address B Reference Register
-
Reserved
DFOPT0
Destination FIFO Options Register 0
DFSRC0
Destination FIFO Source Address Register 0
DFCNT0
Destination FIFO Count Register 0
DFDST0
Destination FIFO Destination Address Register 0
DFBIDX0
Destination FIFO BIDX Register 0
DFMPPRXY0
Destination FIFO Memory Protection Proxy Register 0
-
Reserved
DFOPT1
Destination FIFO Options Register 1
DFSRC1
Destination FIFO Source Address Register 1
DFCNT1
Destination FIFO Count Register 1
DFDST1
Destination FIFO Destination Address Register 1
DFBIDX1
Destination FIFO BIDX Register 1
DFMPPRXY1
Destination FIFO Memory Protection Proxy Register 1
-
Reserved
DFOPT2
Destination FIFO Options Register 2
DFSRC2
Destination FIFO Source Address Register 2
DFCNT2
Destination FIFO Count Register 2
DFDST2
Destination FIFO Destination Address Register 2
DFBIDX2
Destination FIFO BIDX Register 2
DFMPPRXY2
Destination FIFO Memory Protection Proxy Register 2
-
Reserved
DFOPT3
Destination FIFO Options Register 3
DFSRC3
Destination FIFO Source Address Register 3
DFCNT3
Destination FIFO Count Register 3
DFDST3
Destination FIFO Destination Address Register 3
DFBIDX3
Destination FIFO BIDX Register 3
DFMPPRXY3
Destination FIFO Memory Protection Proxy Register 3
-
Reserved
Submit Documentation Feedback
Product Folder Link(s)
:TMS320C6474
SPRS552F – OCTOBER 2008 – REVISED JULY 2010
