HEX ADDRESS
02D0 20CC
02D0 20D0
02D0 20D4
02D0 20D8
02D0 20E0 - 02D0 20E4
02D0 20E8
02D0 20EC
02D0 20F0 - 02D0 20FC
02D0 2100
02D0 2104
02D0 2108
02D0 210C
02D0 2110
02D0 2114
02D0 2118
02D0 211C - 02D0 2124
02D0 2128
02D0 212C
02D0 2130 - 02D1 1FFC
02D1 2000
02D1 2004
02D1 2008
02D1 200C
02D1 2010
02D1 2014
02D1 2018
02D1 201C
02D1 2020 - 02D1 3FFC
02D1 4000
02D1 4004
02D1 4008
02D1 400C
02D1 4010
02D1 4014
02D1 4018 - 02D1 40FC
02D1 4100
02D1 4104
02D1 4108
02D1 410C
02D1 4110
02D1 4114
02D1 4118 - 02D1 42FC
02D1 4200
02D1 4204
02D1 4208
02D1 420C
02D1 4210
Copyright © 2008–2010, Texas Instruments Incorporated
Table 7-79. RapidIO Control Registers (continued)
ACRONYM
SP2_ERR_CAPT_DBG1
SP2_ERR_CAPT_DBG2
SP2_ERR_CAPT_DBG3
SP2_ERR_CAPT_DBG4
-
SP2_ERR_RATE
SP2_ERR_THRESH
-
SP3_ERR_DET
SP3_RATE_EN
SP3_ERR_ATTR_CAPT_DBG0
SP3_ERR_CAPT_DBG1
SP3_ERR_CAPT_DBG2
SP3_ERR_CAPT_DBG3
SP3_ERR_CAPT_DBG4
-
SP3_ERR_RATE
SP3_ERR_THRESH
-
SP_IP_DISCOVERY_TIMER
SP_IP_MODE
IP_PRESCAL
-
SP_IP_PW_IN_CAPT0
SP_IP_PW_IN_CAPT1
SP_IP_PW_IN_CAPT2
SP_IP_PW_IN_CAPT3
-
SP0_RST_OPT
SP0_CTL_INDEP
SP0_SILENCE_TIMER
SP0_MULT_EVNT_CS
-
SP0_CS_TX
-
SP1_RST_OPT
SP1_CTL_INDEP
SP1_SILENCE_TIMER
SP1_MULT_EVNT_CS
-
SP1_CS_TX
-
SP2_RST_OPT
SP2_CTL_INDEP
SP2_SILENCE_TIMER
SP2_MULT_EVNT_CS
-
Submit Documentation Feedback
Product Folder Link(s)
SPRS552F – OCTOBER 2008 – REVISED JULY 2010
REGISTER NAME
Port 2 Packet/Control Symbol Error Capture CSR 1
Port 2 Packet/Control Symbol Error Capture CSR 2
Port 2 Packet/Control Symbol Error Capture CSR 3
Port 2 Packet/Control Symbol Error Capture CSR 4
Reserved
Port 2 Error Rate CSR
Port 2 Error Rate Threshold CSR
Reserved
Port 3 Error Detect CSR
Port 3 Error Enable CSR
Port 3 Attributes Error Capture CSR 0
Port 3 Packet/Control Symbol Error Capture CSR 1
Port 3 Packet/Control Symbol Error Capture CSR 2
Port 3 Packet/Control Symbol Error Capture CSR 3
Port 3 Packet/Control Symbol Error Capture CSR 4
Reserved
Port 3 Error Rate CSR
Port 3 Error Rate Threshold CSR
Reserved
Port IP Discovery Timer in 4x Mode
Port IP Mode CSR
Port IP Prescaler Register
Reserved
Port-Write-In Capture CSR Register 0
Port-Write-In Capture CSR Register 1
Port-Write-In Capture CSR Register 2
Port-Write-In Capture CSR Register 3
Reserved
Port 0 Reset Option CSR
Port 0 Control Independent Register
Port 0 Silence Timer Register
Port 0 Multicast-Event Control Symbol Request Register
Reserved
Port 0 Control Symbol Transmit Register
Reserved
Port 1 Reset Option CSR
Port 1 Control Independent Register
Port 1 Silence Timer Register
Port 1 Multicast-Event Control Symbol Request Register
Reserved
Port 1 Control Symbol Transmit Register
Reserved
Port 2 Reset Option CSR
Port 2 Control Independent Register
Port 2 Silence Timer Register
Port 2 Multicast-Event Control Symbol Request Register
Reserved
Peripheral Information and Electrical Specifications
