www.ti.com
4.4
Priority Allocation
On the C6474 device, each of the masters is assigned a priority via the Priority Allocation Register
(PRI_ALLOC), see
data traffic through the SCR. The priority is enforced when several masters in the system vie for the same
endpoint. The PRI value of 000b has the highest priority, while the PRI value 111b has the lowest priority.
A chip-level register must be provided to set these values for masters that do not have their own register
internally.
The configuration SCR port on the data SCR is considered a single endpoint meaning priority will be
enforced when multiple masters try to access the configuration SCR. Priority is also enforced on the
configuration SCR side when a master (through the data SCR) tries to access the same endpoint as the
C64x+ Megamodule.
The 4-Byte PRI_ALLOC register address range is 0288 083C - 0288 083F.
31
Reserved
RW, +00 0000 0000 0000 0000 0000 0000
All other master peripherals are not present in the PRI_ALLOC register, as they have their own registers
to program their priorities and do not need a default priority setting. For more information on the default
priority values in these peripheral registers, see the device-compatible peripheral reference guides. TI
recommends that these priority registers be reprogrammed upon initial use.
Copyright © 2008–2010, Texas Instruments Incorporated
Figure
4-3. User-programmable priority registers allow software configuration of the
6
5
Figure 4-3. Priority Allocation Register (PRI_ALLOC)
Submit Documentation Feedback
Product Folder Link(s)
SPRS552F – OCTOBER 2008 – REVISED JULY 2010
3
2
RapidIO CPPI
RW, +001
:TMS320C6474
TMS320C6474
0
EMAC
RW, +001
System Interconnect
57
