TMS320C6474
SPRS552F – OCTOBER 2008 – REVISED JULY 2010
31
Reserved
R-00000000
15 14 13 12
TINPHSEL3 TINPLSEL3
R/W-01 R/W-00
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 7-65. Timer Input Selection Register (TINPSEL) Field Descriptions
Bit Field
31-24 Reserved
23:22 TINPHSEL5
21:20 TINPLSEL5
19:18 TINPHSEL4
17:16 TINPLSEL4
15:14 TINPHSEL3
13:12 TINPLSEL3
11:10 TINPHSEL2
160 Peripheral Information and Electrical Specifications
11 10 9
TINPHSEL2 TINPLSEL2
R/W-01 R/W-00
Figure 7-39. Timer Input Selection Register (TINPSEL)
Value Description
Reserved
Input Select for TIMER 5 High
00 TIMI0
01 TIMI1
10 FSEVT2
11 FSEVT3
Input Select for TIMER 5 Low
00 TIMI0
01 TIMI1
10 FSEVT2
11 FSEVT3
Input Select for TIMER 4 High
00 TIMI0
01 TIMI1
10 FSEVT2
11 FSEVT3
Input Select for TIMER 4 Low
00 TIMI0
01 TIMI1
10 FSEVT2
11 FSEVT3
Input Select for TIMER 3 High
00 TIMI0
01 TIMI1
10 FSEVT2
11 FSEVT3
Input Select for TIMER 3 Low
00 TIMI0
01 TIMI1
10 FSEVT2
11 FSEVT3
Input Select for TIMER 2 High
00 TIMI0
01 TIMI1
10 FSEVT2
11 FSEVT3
