Some peripherals can be statically powered down at device reset through the device configuration pins
(see Section 3.1, Device Configuration at Device Reset). Once in a static power-down state, the peripheral
is held in reset and its clock is turned off. Peripherals cannot be enabled once they are in a static
power-down state. To take a peripheral out of the static power-down state, a device reset must be
executed with a different configuration pin setting.
After device reset, all peripherals on the C6474 device are in a disabled state and must be enabled by
software before being used. It is possible to enable only the peripherals needed by the application while
keeping the rest disabled. Note that peripherals in a disabled state are held in reset with their clocks
gated. For more information on how to enable peripherals, see
Device Reset.
Peripherals used for booting, like I2C, are automatically enabled after device reset. It is possible to disable
peripherals used for booting after the boot process is complete. This, too, results in gating of the clock(s)
to the powered-down peripheral. Once a peripheral is powered-down, it must remain powered down until
the next device reset.
The C64x+ Megamodule also allows for software-driven power-down management for all of the C64x+
Megamodule components through its Power-Down Controller (PDC). The CPU can power-down part or
the entire C64x+ Megamodule through the power-down controller based on its own execution thread or in
response to an external stimulus from a host or global controller. More information on the power-down
features of the C64x+ Megamodule can be found in the TMS320C64x+ Megamodule Reference Guide
(literature number SPRU871).
Table 7-2 lists the Power/Sleep Controller (PSC) registers.
HEX ADDRESS
02AC 0000
02AC 0120
02AC 0128
02AC 0200
02AC 0300
02AC 0304
02AC 0308
02AC 030C
02AC 0310
02AC 0314
02AC 0800
02AC 0804
02AC 0808
02AC 080C
02AC 0810
02AC 0814
02AC 0818
02AC 081C
02AC 0820
02AC 0824
02AC 0828
02AC 082C
02AC 0A00
02AC 0A04
02AC 0A08
Copyright © 2008–2010, Texas Instruments Incorporated
Table 7-2. Power/Sleep Controller Registers
ACRONYM
PID Peripheral Revision and Class Information
PTCMD Power Domain Transition Command Register
PTSTAT Power Domain Transition Status Register
PDSTAT Power Domain Status Register
PDCTL0 Power Domain Control Register 0 (AlwaysOn)
PDCTL1 Power Domain Control Register 1 (Antenna Interface)
PDCTL2 Power Domain Control Register 2 (Serial RapidIO)
- Reserved
PDCTL4 Power Domain Control Register 4 (TCP)
PDCTL5 Power Domain Control Register 5 (VCP)
- Reserved
- Reserved
- Reserved
MDSTAT3 Module Status Register 3 (C64x+ Core 0)
MDSTAT4 Module Status Register 4 (C64x+ Core 1)
MDSTAT5 Module Status Register 5 (C64x+ Core 2)
MDSTAT6 Module Status Register 6 (Antenna Interface)
MDSTAT7 Module Status Register 7 (Serial RapidIO)
- Reserved
MDSTAT9 Module Status Register 9 (TCP)
MDSTAT10 Module Status Register 10 (VCP)
MDSTAT11 Module Status Register 11 (Never Gated)
- Reserved
- Reserved
- Reserved
