7.15.3 Timers Electrical Data/Timing
(see Figure 7-42)
NO.
1 t Pulse duration, TIMI high
w(TIMH)
2 t Pulse duration, TIMI low
w(TIMIL)
(1) C = 1/CPU Clock, in ns.
Table 7-76. Switching Characteristics Over Recommended Operating Conditions for Timer Outputs
(see Figure 7-42)
NO.
3 t Pulse duration, TIMO high
w(TIMOH)
4 t Pulse duration, TIMO low
w(TIMOL)
(1) If CORECLKSEL = 0, C = 1/SYSCLK(NIP) frequency, in ns. If CORECLKSEL = 1, C = 1/ALTCORECLK (N|P) frequency, in ns.
166 Peripheral Information and Electrical Specifications
Table 7-75. Timing Requirements for Timer Inputs
PARAMETER
PARAMETER
Figure 7-42. Timer Timing
Submit Documentation Feedback
Product Folder Link(s)
(1)
Copyright © 2008–2010, Texas Instruments Incorporated
:TMS320C6474
www.ti.com
MIN MAX UNIT
12C ns
12C ns
(1)
MIN MAX UNIT
12C - 3 ns
12C - 3 ns
