Texas Instruments TMS320C6474 Manual page 93

www.ti.com
HEX ADDRESS
02A0 2A1C
02A0 2A20
02A0 2A24
02A0 2A28
02A0 2A2C
02A0 2A30
02A0 2A34
02A0 2A38
02A0 2A3C
02A0 2A40
02A0 2A44
02A0 2A48 - 02A0 2A4C
02A0 2A50
02A0 2A54
02A0 2A58
02A0 2A5C
02A0 2A60
02A0 2A64
02A0 2A68
02A0 2A6C
02A0 2A70
02A0 2A74
02A0 2A78
02A0 2A7C
02A0 2A80
02A0 2A84
02A0 2A88
02A0 2A8C
02A0 2A90
02A0 2A94
02A0 2A98 - 02A0 2BFF
02A0 2C00
02A0 2C04
02A0 2C08
02A0 2C0C
02A0 2C10
02A0 2C14
02A0 2C18
02A0 2C1C
02A0 2C20
02A0 2C24
02A0 2C28
02A0 2C2C
02A0 2C30
02A0 2C34
02A0 2C38
Copyright © 2008–2010, Texas Instruments Incorporated
Table 7-5. EDMA3 Registers (continued)
ACRONYM
CERH Chained Event Register Hig
EER Event Enable Register
EERH Event Enable Register High
EECR Event Enable Clear Register
EECRH Event Enable Clear Register High
EESR Event Enable Set Register
EESRH Event Enable Set Register High
SER Secondary Event Register
SERH Secondary Event Register High
SECR Secondary Event Clear Register
SECRH Secondary Event Clear Register High
- Reserved
IER Interrupt Enable Register
IERH Interrupt Enable Register High
IECR Interrupt Enable Clear Register
IECRH Interrupt Enable Clear Register High
IESR Interrupt Enable Set Register
IESRH Interrupt Enable Set Register High
IPR Interrupt Pending Register
IPRH Interrupt Pending Register High
ICR Interrupt Clear Register
ICRH Interrupt Clear Register High
IEVAL Interrupt Evaluate Register
- Reserved
QER QDMA Event Register
QEER QDMA Event Enable Register
QEECR QDMA Event Enable Clear Register
QEESR QDMA Event Enable Set Register
QSER QDMA Secondary Event Register
QSECR QDMA Secondary Event Clear Register
- Reserved
Shadow Region 6 Channel Registers
ER Event Register
ERH Event Register High
ECR Event Clear Register
ECRH Event Clear Register High
ESR Event Set Register
ESRH Event Set Register High
CER Chained Event Register
CERH Chained Event Register Hig
EER Event Enable Register
EERH Event Enable Register High
EECR Event Enable Clear Register
EECRH Event Enable Clear Register High
EESR Event Enable Set Register
EESRH Event Enable Set Register High
SER Secondary Event Register
Submit Documentation Feedback
Product Folder Link(s)
SPRS552F – OCTOBER 2008 – REVISED JULY 2010
REGISTER NAME
Peripheral Information and Electrical Specifications
:TMS320C6474
TMS320C6474
93
