www.ti.com
HEX ADDRESS
02A0 036C
02A0 0370
02A0 0374
02A0 0378
02A0 037C
02A0 0380
02A0 0384
02A0 0388
02A0 038C
02A0 0390
02A0 0394
02A0 0398
02A0 039C
02A0 0400
02A0 0404
02A0 0408
02A0 040C
02A0 0410
02A0 0414
02A0 0418
02A0 041C
02A0 0420
02A0 0424
02A0 0428
02A0 042C
02A0 0430
02A0 0434
02A0 0438
02A0 043C
02A0 0440
02A0 0444
02A0 0448
02A0 044C
02A0 0450
02A0 0454
02A0 0458
02A0 045C
02A0 0460
02A0 0464
02A0 0468
02A0 046C
02A0 0470
02A0 0474
02A0 0478
02A0 047C
02A0 0480
02A0 0484
Copyright © 2008–2010, Texas Instruments Incorporated
Table 7-5. EDMA3 Registers (continued)
ACRONYM
DRAEH5 DMA Region Access Enable Register High for Region 5
DRAE6 DMA Region Access Enable Register for Region 6
DRAEH6 DMA Region Access Enable Register High for Region 6
DRAE7 DMA Region Access Enable Register for Region 7
DRAEH7 DMA Region Access Enable Register High for Region 7
QRAE0 QDMA Region Access Enable Register for Region 0
QRAE1 QDMA Region Access Enable Register for Region 1
QRAE2 QDMA Region Access Enable Register for Region 2
QRAE3 QDMA Region Access Enable Register for Region 3
QRAE4 QDMA Region Access Enable Register for Region 4
QRAE5 QDMA Region Access Enable Register for Region 5
QRAE6 QDMA Region Access Enable Register for Region 6
QRAE7 QDMA Region Access Enable Register for Region 7
Q0E0 Event Queue 0 Entry Register 0
Q0E1 Event Queue 0 Entry Register 1
Q0E2 Event Queue 0 Entry Register 2
Q0E3 Event Queue 0 Entry Register 3
Q0E4 Event Queue 0 Entry Register 4
Q0E5 Event Queue 0 Entry Register 5
Q0E6 Event Queue 0 Entry Register 6
Q0E7 Event Queue 0 Entry Register 7
Q0E8 Event Queue 0 Entry Register 8
Q0E9 Event Queue 0 Entry Register 9
Q0E10 Event Queue 0 Entry Register 10
Q0E11 Event Queue 0 Entry Register 11
Q0E12 Event Queue 0 Entry Register 12
Q0E13 Event Queue 0 Entry Register 13
Q0E14 Event Queue 0 Entry Register 14
Q0E15 Event Queue 0 Entry Register 15
Q1E0 Event Queue 1 Entry Register 0
Q1E1 Event Queue 1 Entry Register 1
Q1E2 Event Queue 1 Entry Register 2
Q1E3 Event Queue 1 Entry Register 3
Q1E4 Event Queue 1 Entry Register 4
Q1E5 Event Queue 1 Entry Register 5
Q1E6 Event Queue 1 Entry Register 6
Q1E7 Event Queue 1 Entry Register 7
Q1E8 Event Queue 1 Entry Register 8
Q1E9 Event Queue 1 Entry Register 9
Q1E10 Event Queue 1 Entry Register 10
Q1E11 Event Queue 1 Entry Register 11
Q1E12 Event Queue 1 Entry Register 12
Q1E13 Event Queue 1 Entry Register 13
Q1E14 Event Queue 1 Entry Register 14
Q1E15 Event Queue 1 Entry Register 15
Q2E0 Event Queue 2 Entry Register 0
Q2E1 Event Queue 2 Entry Register 1
Submit Documentation Feedback
Product Folder Link(s)
SPRS552F – OCTOBER 2008 – REVISED JULY 2010
REGISTER NAME
Peripheral Information and Electrical Specifications
:TMS320C6474
TMS320C6474
85
