7.15.1.2 Timer Watchdog Select
As mentioned previously, the timers can operate in watchdog mode. When in watchdog mode, the event
output from the timer can optionally reset the CPU. When used in this type of mode, Timer3, Timer4, and
Timer 5 correspond to C64x+ Megamodule Core 0, C64x+ Megamodule Core 1, and C64x+ Megamodule
Core 2, respectively. In order for the event not to trigger the reset when this operation is not desired, the
Timer watchdog reset selection register (WDRSTSEL) is created to turn this feature on/off. The
WDRSTSEL register is shown in
31
7
R-0 0000 0000 0000 0000 0000 0000 0000
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Figure 7-41. Timer Watchdog Reset Selection Register (WDRSTSEL)
Table 7-67. Timer Watchdog Reset Selection Register (WDRSTSEL) Field Descriptions
Bit Field
31:3 Reserved
2:2 WRDSTSELn
7.15.2 Timers Peripheral Description(s)
HEX ADDRESS
0291 0000
0291 0004
0291 0008
0291 000C
0291 0010
0291 0014
0291 0018
0291 001C
0291 0020
0291 0024
0291 0028
0291 002C
0291 0030
0291 0034 - 0291 FFFF
