7.15.1.1.2 Timer Output Selection Register (TOUTPSEL)
The timer output selection is handled in the Timer output selection register (TOUTPSEL). The TOUTPSEL
register is shown in
31
15
Reserved
R-000000000000000000000000
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 7-66. Timer Output Selection Register (TOUTPSEL) Field Descriptions
Bit Field
31:8 Reserved
7:4 TOUTPSEL1
3:0 TOUTPSEL0
162 Peripheral Information and Electrical Specifications
Figure 7-40 and described in
R-000000000000000000000000
Figure 7-40. Timer Output Selection Register (TOUTPSEL)
Value Description
Reserved
Output Select for TIMI1
0000 TOUTL0
0001 TOUTH0
0010 TOUTL1
0011 TOUTH1
0100 TOUTL2
0101 TOUTH2
0110 TOUTL3
0111 TOUTH3
1000 TOUTL4
1001 TOUTH5
1010 TOUTL5
1011 TOUTH5
Other Reserved
Output Select for TIMO0
0000 TOUTL0
0001 TOUTH0
0010 TOUTL1
0011 TOUTH1
0100 TOUTL2
0101 TOUTH2
0110 TOUTL3
0111 TOUTH3
1000 TOUTL4
1001 TOUTH5
1010 TOUTL5
1011 TOUTH5
Other Reserved
