For detailed output description, see the corresponding command manual.
SNMP Test Network requirements
Both the Remote-Ping client and the SNMP Agent are Switch 4210s. Perform
Remote-Ping SNMP tests between the two switches to test the time required from
Switch A sends an SNMP query message to Switch B (SNMP Agent) to it receives a
response from Switch B.
Network diagram
Figure 185 Network diagram for the SNMP test
Switch A
HWPing Client
Configuration procedure
Configure SNMP Agent (Switch B):
■
# Start SNMP agent and set SNMP version to V2C, read-only community name
to "public", and read-write community name to "private".
<Sysname> system-view
[Sysname] snmp-agent
[Sysname] snmp-agent sys-info version v2c
[Sysname] snmp-agent community read public
[Sysname] snmp-agent community write private
n
The SNMP network management function must be enabled on SNMP agent
■
before it can receive response packets.
The SNMPv2c version is used as reference in this example. This configuration
■
may differ if the system uses any other version of SNMP. For details, see SNMP -
RMON Operation Manual.
Configure Remote-Ping Client (Switch A):
■
# Enable the Remote-Ping client.
<4210> system-view
[4210] Remote-Ping-agent enable
# Create a Remote-Ping test group, setting the administrator name to
"administrator" and test tag to "snmp".
[4210] Remote-Ping administrator snmp
# Configure the test type as snmp.
[4210-Remote-Ping-administrator-snmp] test-type snmpquery
# Configure the destination IP address as 10.2.2.2.
[4210-Remote-Ping-administrator-snmp] destination-ip 10.2.2.2
# Configure to make 10 probes per test.
[4210-Remote-Ping-administrator-snmp] count 10
# Set the probe timeout time to 30 seconds.
IP n etwork
10.1.1.1/8
Remote-Ping Configuration Example
10.2.2.2/8
Switch B
SNMP Agent
