Configuring Leaf
Nodes
Table 120 Enable MSTP in Ethernet port view
Operation
Disable MSTP on the port
Other MSTP-related settings can take effect only after MSTP is enabled on the
switch.
Configuration example
# Enable MSTP on the switch and disable MSTP on Ethernet 1/0/1.
1 Perform this configuration in system view
<4210> system-view
[4210] stp enable
[4210] stp interface Ethernet1/0/1 disable
2 Perform this configuration in Ethernet port view
<4210> system-view
[4210] stp enable
[4210] interface Ethernet1/0/1
[4210-Ethernet1/0/1] stp disable
Table 121 lists the tasks to configure a leaf node.
Table 121 Configure leaf nodes
Operation
Enable MSTP
Configure the MST region
Configure the mode a port
recognizes and sends MSTP
packets
Configure the timeout time
factor
Configure the maximum
transmitting speed on the
current port
Command
stp disable
Description
Required
To prevent network topology
jitter caused by other related
configurations, you are
recommended to enable
MSTP after performing other
configurations.
Required
Optional
Optional
Optional
The default value is
recommended.

Configuring Leaf Nodes

167
Description
Optional
By default, MSTP is enabled
on all ports after you enable
MSTP in system view.
To enable a switch to operate
more flexibly, you can disable
MSTP on specific ports. As
MSTP-disabled ports do not
participate in spanning tree
calculation, this operation
saves CPU resources of the
switch.
Related section
"Enabling MSTP"
"Configuring an MST Region"
"Configuring the Mode a Port
Recognizes and Sends MSTP
Packets"
"Configuring the Timeout
Time Factor"
"Configuring the Maximum
Transmitting Speed on the
Current Port"
