HP ProCurve 420 Management And Configuration Manual page 245

C a u t i o n
Restore Factory Settings: Click the Restore button to reset the access
■
point's configuration settings to the factory defaults and reboot the
system.
■ Reset Access Point: Click the Reset button to reboot the system.
To Download New Software Using FTP or TFTP:
1. Select the Administration tab.
2. Click the [ Software Upgrade]
3. Under Software Upgrade Remote, select FTP or TFTP for the server you are
using.
4. In the text field New Software File, specify the file name of the software
on the FTP or TFTP server.
5. In the text field IP Address, specify the IP address of the FTP or TFTP
server.
6. If using an FTP server, specify the user name and password, if required.
7. Click the [Start Upgrade]
8. When the download is complete, restart the access point by clicking on
the button. Alternatively, you can reset the access point defaults
[Reboot]
and reboot the system by clicking on the
access point is highly recommended.
New software that is incompatible with the current configuration automati­
cally restores the access point to default values when first activated after a
reboot.
Downloading Access Point Software
button.
button.
[Reset]
File Transfers
button. Resetting the
A-5
