N o t e
Configuring Ethernet Interface
Parameters
The access point's Ethernet interface can be configured to use auto-negotia­
tion to set the operating speed and duplex mode. When auto-negotiation is
disabled, the operating speed and duplex mode must be manually set to match
that of the connected device. Auto-negotiation is enabled by default.
When using auto-negotiation, be sure that the attached device supports
IEEE 802.3u standard auto-negotiation and is not set to a forced speed and
duplex mode.

Web: Setting Ethernet Interface Parameters

The Port/Radio Settings window on the Configuration tab enables the access
point's Ethernet interface settings to be configured.
The web interface enables you to modify these parameters:
Auto: The Ethernet interface automatically sets the operating speed and
■
duplex mode to match that of the attached device.
■ 100Base-TX Full Duplex: The Ethernet interface is set to operate at
100 Mbps full duplex.
100Base-TX Half Duplex: The Ethernet interface is set to operate at
■
100 Mbps half duplex.
10Base-T Full Duplex: The Ethernet interface is set to operate at
■
10 Mbps full duplex.
■ 10Base-T Half Duplex: The Ethernet interface is set to operate at
10 Mbps half duplex.
To Configure Ethernet Interface Settings:
Select the Configuration tab.
1.
2. Click the [ Port/Radio Settings]
3. Under Port Settings, select the setting to match that of the connected
device; either Auto or one of the forced speed and duplex mode options.
4. Click the [Apply Changes]
To display the current operating status for the Ethernet interface, use the AP
Status window on the Status tab. See "The AP Status Window" on page 4-17.

Configuring Ethernet Interface Parameters

button.
button.
Access Point Configuration
5-39
