HP ProCurve 420 Management And Configuration Manual page 80

Access Point Configuration
Configuring SNMP
Figure 5-6. Creating SNMP v3 Trap Targets and Filters
5-22
SNMP Trap Filters: Configures SNMP v3 trap filters.
■
• Filter ID – A user-defined name that identifies the filter. (Maximum
length: 32 characters)
• Subtree OID – Specifies the MIB subtree to be filtered. The OID can
specify one trap or include all the traps under the OID subtree. The
MIB subtree must be defined in the form ".1.3.6.1" and always start
with a ".". A full list of supported traps and OIDs are provided on page
5-27. The
[Edit]
same filter.
• Filter Type – Indicates if the MIB subtree traps specified by the
Subtree OID are to be sent to the receiving target.
– Include: The MIB subtree traps are to be sent to the assigned
receiving target.
– Exclude: The MIB subtree traps are not to be sent to the assigned
receiving target.
button can be used to add up to 20 OID subtrees to the
