Figure 14 How the router connects the source to the destination network
36
NetWare TCP/IP Administration Guide
Token Ring
Network
130.58.0.0
130.58.1.2
Each host has a default router or a list of routers in other networks. When IP
sends a datagram the following happens:
1. IP searches the routing table of the sending node for a default route or a
path to the destination IP address.
2. IP extracts the address of the default router or next-hop router from the
route entry.
3. IP requires ARP to map the next-hop address to its hardware address.
4. IP transmits the packet to the next hop.
5. IP repeats Steps 1 through 4 until the final destination is reached.
130.58.1.1
Router
Ethernet
Network
140.88.0.0
140.88.12.1
140.88.3.4
