Slot—Number of the slot where the board is installed.
Status—Status of the board, which is Enabled by default.
Comment—Any comments that you enter about the board or its
configuration.
NOTE:
Not every board-driver configuration requires all this information; in fact,
some configurations require other, link-specific parameters that are not shown in
the Configured Boards screen. These parameters are displayed in the Board
Configuration menu, as described in the following steps.
If the board driver has an .LDI file, the parameters you need to configure
for the board are displayed as separate fields in the menu.
If the board driver has no .LDI file, only the Board Name, Board
Parameters, and Comment fields are provided as a means for entering the
parameters manually.
4
Specify the board parameters by doing one of the following:
If the driver selected has a description file, the parameters are listed
as separate fields. You must highlight each field one at a time and
select the appropriate value for the parameter from the displayed list.
HINT:
Use the context-sensitive help text if you need an explanation of any
parameter. Highlight the parameter and press F1 to display the help text.
Press Esc to exit the help screen. When in doubt, accept the default values.
If the driver selected does not have a description file, the Board
Configuration Without A Driver Description File menu is displayed.
You must type the parameters in the Board Parameters field; use the
following as an example:
PORT=300 INT=3
These parameters are appended to the LOAD driver line.
5
Press Esc to return to the Configured Boards screen; save your changes
when prompted.
The Configured Boards screen now shows the board you just configured.
Note that the board status is Enabled; you can use the Tab key to toggle
between Enabled and Disabled. To ensure that the board is loaded,
continue with the next step.
6
Press Esc to return to the Internetworking Configuration menu; save your
changes when prompted.
7
If you want these changes to take effect immediately, perform the
following actions.
