Loading INETCFG

Configuring a LAN Board

48
NetWare TCP/IP Administration Guide
To load INETCFG at from the server prompt enter
inetcfg
The Internetworking Console interface is displayed. For the next set of
operation you need to select options on the Internetworking Console screens.
To configure a board, complete the following steps:
1
Load INETCFG and then click Boards.
2
Do one of the following:
2a
If you are configuring a new board:
Press Ins to display the list of available drivers.
Scroll through the list of available drivers and select the driver that
corresponds to the type of new LAN board you are installing in your
system. If the driver you need is not in the list, refer to
New Board Driver or NLM File to Your System" on page
2b
If you are changing an existing board configuration:
Select that board.
Press Enter to see the configured parameters of the board.
Change the required parameters. (The name can not be
changed.)
3
The Configured Boards screen is displayed.
NOTE:
If you are doing a new configuration, no existing boards are shown.
Otherwise, boards that have already been configured are shown.
The Configured Boards screen displays a list of configured boards with
some or all of the following information:
Board Name—Name you assign to the board.
Driver—Name of the driver associated with the board.
Int—Interrupt request level (IRQ) used by the board.
IOAddr—Base input/output port address for the board.
MemAddr—Base memory address used by the board.
"Adding a
50.
