iPrint Administration Guide
made outside of the iPrint Map Designer are not supported. If you need to add
links to a map, you should create a frameset file and then display the map file
in one frame and display your links in a different frame.
Creating a Map
1
Copy all of your background images (maps) to
SYS:LOGIN\IPPDOCS\IMAGES\MAPS on the server.
File types that can be used for background images are .JPEG, .GIF, and
.BMP.
2
Do one of the following:
Using a mapped drive, open
SYS:LOGIN\IPPDOCS\MAPTOOL.HTM in Microsoft Internet
Explorer.
Open http://server_address:port/login/ippdocs/maptool.htm where
server_address is the server's IP address or DNS name of the server
where the printer agent is running.
3
Click Background and select an image from
SYS:LOGIN\IPPDOCS\IMAGES\MAPS.
4
To add a printer to the map, select the Printer icon and the printer size.
5
Drag and drop the printer onto the map in the design area.
6
Next to the Printer List field, click the Browse icon and enter the IP
address or DNS name of the server where the print services manager is
running.
7
From the Printer list, select the printer agent you want associated with this
printer icon.
If the printer is not listed, then you have not enabled IPP for the printer.
See "Configuring iPrint Printers" on page 16
The Printer URL and Mouse Over Text is automatically filled in with the
printer agent information.
Printer URL: The URL created for the printer when IPP is enabled for
the printer. You should not need to change the URL.
Mouse Over Text: By default, displays the printer agent's name. You can
override this information by entering the text you want to display when a
user moves the mouse over the Printer icon.
for more information.
