Deleting a LAN Board
Enabling TCP/IP
and reinitialize the system. To avoid this problem, use INETCFG to load both
drivers.
3
Press Esc to return to the Internetworking Configuration menu.
1
Load INETCFG and then click Boards
2
Select the board you want to delete and press Del.
A message is displayed indicating that deleting the board also deletes all
existing binds to the board's interfaces.
3
When prompted, select Yes to delete the board.
The board is removed from the list of configured boards.
4
Press Esc to return to the Internetworking Configuration menu.
5
Reinitialize system for the changes to take place.
1
Load INETCFG and then click Protocols.
2
Select TCP/IP from the list of protocols.
3
In the TCP/IP screen, enable or disable the following:
TCP/IP
IP Packet Forwarding
OSPF
LAN Static Routing
Dead Gateway Detection
SNMP Manager
DNS Resolver
Load Balancing
Fault Tolerance
Filter Support
NAT Implicit Filtering
Expert Configuration
51
Setting Up
