I Your first contact
Now that you have your IC-2200H installed in your car or
shack, you are probably excited to get on the air. We would
like to take you through a few basic operation steps to make
your first "On The Air" an enjoyable experience.
1. Turning ON the transceiver
Before powering up your IC-2200H, you may want to make
sure the audio volume and squelch level controls are set in
9–10 o'clock positions.
[VOL]
[SQL]
Set both [VOL] and [SQL] controls to
9–10 o'clock positions.
Although you have purchased a brand new transceiver, some
settings may be changed from the factory defaults because
of the QC process. Resetting the CPU is necessary to start
from factory default.
[PWR] [SET LOCK]
➥ While pushing [SET
LOCK
[PWR] for 1 sec. to reset the CPU.
[S.MW MW]
] and [S.MW MW ], push
QUICK REFERENCE GUIDE
2. Tune the desired frequency
[DIAL] will allow you to dial in the frequency you want to op-
erate. Pages 9 and 11 will instruct you on how to set the tun-
ing speed.
Using the HM-133V
You can directly enter the frequency with the HM-133V keypad.
[EXAMPLE]: Setting frequency to 145.3625 MHz.
MUTE
NAR
Push
MID
LOW
MUTE
NAR
Push
MID
LOW
Push
MUTE
NAR
MID
LOW
MUTE
Push NAR
MID
LOW
We hope these pointers have been helpful. Now you
are ready to call CQ.
[DIAL]
DIGITAL PRIO AO BUSY
LOCK ANM DUP T-SCAN PRIO SCAN
S ET MONI LOW TONE M/CALL V/ MHz
DIGITAL PRIO AO BUSY
LOCK ANM DUP T-SCAN PRIO SCAN
S ET MONI LOW TONE M/CALL V/ MHz
DIGITAL PRIO AO BUSY
LOCK ANM T-SCAN PRIO SCAN
DUP
S ET MONI LOW TONE M/CALL V/ MHz
DIGITAL PRIO AO BUSY
LOCK ANM DUP T-SCAN PRIO SCAN
S ET MONI LOW TONE M/CALL V/ MHz
IV
