QUICK REFERENCE GUIDE
I Your first contact
Now that you have your IC-E208 installed in your car or
shack, you are probably excited to get on the air. We would
like to take you through a few basic operation steps to make
your first "On The Air" an enjoyable experience.
1. Turning ON the transceiver
Before powering up your IC-E208, you may want to make
sure the audio volume and squelch level controls are set in
9–10 o'clock positions.
Set [VOL] and [SQL] controls to 9–10 o'clock positions.
Although you have purchased a brand new transceiver, some
settings may be changed from the factory defaults because
of the QC process. Resetting the CPU is necessary to start
from factory default.
[SET•LOCK]
[S.MW•MW]
While pushing [SET•LOCK] and [S.MW•MW], turn power ON.
➥ While pushing both [SET•LOCK] and [S.MW•MW], push
[PWR] for 1 sec. to reset the CPU.
VII
2. Selecting the operating frequency band
The IC-E208 has 2 m and 70 cm transmittable bands.
➥ Push [BAND] to select the desired frequency band.
[VOL]
Using the HM-133
You can select the desired frequency band from the HM-133.
[SQL]
[PWR]
[BAND]
Push [BAND] to select the desired frequency band.
Push
Push
