D D When calling the desired station
y Select the desired call sign.
- Push [BANK OPT ] twice to select the call sign select mode.
• "YUC" appears.
- Rotate [DIAL] to select the desired call sign (pre-pro-
grammed), or set the desired call sign. (see pgs. 59, 60)
DIGITAL
MUTE
NAR
MID
LOW
LOCK ANM DUP T-SCAN
S ET MONI LOW TONE
- Push any key other than indicated function keys to exit
option set mode.
DIGITAL
MUTE
NAR
MID
LOW
LOCK ANM DUP T-SCAN
S ET MONI LOW TONE
uPush and hold [PTT] to transmit and speak into the micro-
phone at normal voice level.
• Transmit indicator appears and the RF meter shows the output power.
i Release [PTT] to return to receive.
• The other station call sign will be received.
• Received call signs can be stored into the received call record
automatically. See page 63 for details.
NOTE: The digital mode operation is vastly different than FM
mode. One of the differences is in the digital mode the
squelch does not function as FM mode, changing the squelch
setting will not open to hear the hiss of "White Noise," only
activate for digital squelch function as CSQL (Digital code
squelch), DSQL (Call sign squelch) or S-meter squelch.
PRIO AO BUSY
PRIO SCAN
M/CALL V/ MHz
PRIO AO BUSY
PRIO SCAN
M/CALL V/ MHz
DIGITAL MODE OPERATION
n Select the desired call sign.
BANK/OPTION
- Push [BANK/OPTION] twice to select the
call sign select mode.
• "YUC" appears.
- Push [Y Y ] or [Z Z ] to select the desired call
sign (pre-programmed), or set the desired
call sign. (see p. 60)
- Push [
CLR
mode.
m Push and hold [PTT] to transmit and speak
into the microphone at normal voice level.
• Transmit indicator appears and the RF meter
shows the output power.
, Release [PTT] to return to receive.
• The other station call sign will be received.
• Received call signs can be stored into the re-
ceived call record automatically. See page 63
for details.
12
A(MW)] to exit option set
