8
OPERATION
8.2.1

LEDs

52 O P E R A T I N G I N S T R U C T I O N S | GM32 Ex
Measuring
Alignment
V1: 410
V2: 379
V3: 389
V4: 417
X: -0.011
Y: 0.024
/Menü/Align
Back
Figure 29: Operating and display elements (with example menu)
Status bar
1
Current menu
2
Current menu index
3
Display of values
4
Current menu branch
5
Significance of function buttons (menu-dependent)
6
Function buttons
7
Status LED
8
Contrast symbol
9
"MEAS" button
ß
To activate a function button: Simply touch the button surface with a finger.
►
LED Significance / possible cause
The device is switched on, power voltage is available.
POWER
• At least one error code is active.
• The "Maintenance operation" state is activated manually.
FAILURE
At least one error code is active.
MAINTENANCE
REQUEST
1
2 POWER
1.2
3
FAILURE
4
MAINTENANCE
REQUEST
5
6
7
8
9
ß
