TROUBLESHOOTING
Table 18: Error table: Failure / Xtended / Uncertain
Initiator Text
Bad Config. (text)
File I/O (text)
Measurement range x Xtended.
Measurement value
out of range
Measurement value
range warning
Medium pressure out
of range
Medium pressure
warning
Medium temperature
out of range
Medium temperature
warning
Gas com‐
ponent
Absorption range
warning
Absorption out of
range
Syntax error
Processing error
Numerical (Div-Zero)
Numerical (IppError)
Numerical (MatSing)
OS error (text)
Spectr. resolution out
of range
Spectral evaluation
Table 19: Initiator key
System
CDH
CDR
P
T
NOTE
This Table also contains recommended solutions that can only be performed by specially trained personnel.
78 O P E R A T I N G I N S T R U C T I O N S | GM32 Ex
Classifica‐ Description
tion
Failure Error in calculation models.
Error in file system.
Failure
Current measuring range x ( x = 1 ... 8).
Measured value outside calibration range.
Uncertain
Measurement beyond a warning threshold
Xtended
defined during calibration.
Sample gas pressure outside calibrated
Uncertain
range.
Sample gas pressure beyond warning
Xtended
threshold.
The measurement on the control filters
Uncertain
showed a deviation that is too high.
The check of the position of the peak of the
Xtended
NO cell showed an excess deviation.
• Absorption in active measuring path
Xtended
above warning threshold.
• Standard setting of warning threshold:
1,8 extinction units.
Failure
Error in concentration calculation.
Failure
Failure
Failure
Numerical error in concentration calcula‐
tion.
Failure
Failure
Error in operating system.
Failure
Resolution of spectrometer wrong.
Failure
Uncertain Error in calculation of spectra.
Possible causes/remedy
Please contact SICK Customer Service.
• Restart system. If the error continues to
exist:
• Please contact SICK Customer Service.
--
Check measured values for plausibility.
Check sample gas pressure.
Check sample gas temperature.
Check:
• Window dirty?
page
• Dust content in sample gas too high?
• Sample gas concentration too high?
Please contact SICK Customer Service.
• Restart system. If the error continues to
exist:
• Please contact SICK Customer Service.
Please contact SICK Customer Service.
S/R unit
Purge air fixture S/R side
Purge air fixture Reflector side
Pressure sensor
Temperature sensor
Gas component
see "Cleaning the window",
65.
