6.5

Connecting pressure, temperature and purge air monitor

8015558/1O6S/V1-9/2024-08 | SICK
Subject to change without notice
1 Lead the cable through the 2 M screw fittings, see Figure below.
2 Plug in the M12 Ethernet connector and screw tight, see Figure below.
3 Connect the cables in the connection unit,
page 40.
4 Screw the M4 screws tight.
5 Push on the connector housing and screw tight.
2
1
3
Figure 16: Connecting hose, S/R unit/connec‐
tion unit
2 M screw fittings
1
Ethernet connector
2
Connector housing
3
NOTE
Purge air monitor - pressure controller for purge air monitoring
•
Wiring diagram, see "Connection overview", page
•
Terminal assignment,
•
Observe the Operating Instructions of the sensors and the purge air monitor.
ELECTRICAL INSTALLATION
see "Preparing the power supply",
see "Connection diagram for variant 3G", page
O P E R A T I N G I N S T R U C T I O N S | GM32 Ex
32.
34.
