8.2.2

Function buttons

8015558/1O6S/V1-9/2024-08 | SICK
Subject to change without notice
Button Function
MEAS Back to the Measuring screen from any menu. All inputs that have not been
terminated with Save are discarded.
F
To set the contrast: Press the MEAS button for more than 3 seconds,
ting the display contrast", page
The current function of the function buttons is shown on the display.
Display Function
Back Return to the higher level menu.
Press <Save> to store any changes made. Otherwise the changes are lost.
Diag Diag only appears when a message is pending.
To display the message: Press this button.
Enter Call up/start selected menu function.
Menu Call up the main menu.
If the <Menu> button is not shown: Press MEAS first.
Save Save input/exit.
Set Start setting.
Select Select function/character.
Start Start procedure.
In a selection list: Move cursor upwards.
During input: Next character.
Move cursor downwards.
Move cursor to the left.
Move cursor to the right.
54.
