9.7
Cleaning the window
9.8
Checking and replacing the desiccant cartridges
8015558/1O6S/V1-9/2024-08 | SICK
Subject to change without notice
Required material
Optical cleaning cloth
Demineralized water
1
Figure 34: Window
Window
1
1
Swiveling the SR-unit out
2
Clean the window with an optical cleaning cloth and demineralized water.
NOTICE
Do not use cleaning agents.
3
Close the SR-unit again.
4
Set the lever on the purge air fixture to the "Close" position".
Material required
Key (delivered with desiccant cartridge)
Desiccant cartridge (1)
The desiccant cartridges are in the sender/receiver unit next to the window.
Part No.
4003353
see "Swiveling out and removing the SR-unit", page
Part No.
4020395
2010549
O P E R A T I N G I N S T R U C T I O N S | GM32 Ex
9
MAINTENANCE
63.
65
