6.10

Connecting the potential equalization to the SR-unit

8015558/1O6S/V1-9/2024-08 | SICK
Subject to change without notice
1
Figure 20: Power connection in connection unit for version 3G
Power supply 100 ... 230 V / 50 .. 60 Hz
1
NOTICE
Always connect a protective conductor to PE.
Figure 21: Connecting the potential equalization on the SR-unit
Potential equalization connection
1
Screw the grounding conductor (4 mm
►
screw terminal.
ELECTRICAL INSTALLATION
1
) of the equipment ground tight to the
2
O P E R A T I N G I N S T R U C T I O N S | GM32 Ex
6
41
